General specifications

Projector type

Three chip DLP

Technology

3 x 0.90" DMD™ with sealed core

Resolution

3,840 x 2,160 (4K UHD)

Aspect ratio

1.78:1 (16:9)

Light source

Laser phosphor

Light source lifetime

Up to 20,000

Light output

Up to 7,500 ANSI Lumems

Dimable to 4,000 lumens

CLO (constant light output)

Yes

Contrast ratio

20,000:1 (with DynaBlack enabled)

2,000:1 Sequential

600:1 ANSI

Brightness uniformity

>90%

Lens range

(R9801661) - TLD+ (0.41:1) - 90 Degree Lens

(R9862001) - TLD+ (0.73 - 0.94:1) - 90 Degree Lens

(R9801414) - TLD+ (0.92 - 1.33:1)

(R9862005 ) - TLD+ (1.24 - 1.56:1)

(R9862010) - TLD+ (1.49 - 2.02:1) *

(R9862020) - TLD+ (2.01 - 2.76:1) *

(R9862030) - TLD+ (2.69 - 4.41:1) *

(R9862040) - TLD+ (4.37 - 7.35:1) *

(R9829997) - TLD+ (6.95 - 10.83:1)

* Standard Lens Option(s)

Optical lens shift

Up to 73% vertical lens shift & up to 28% horizontal lens shift (depending on lens selection) Visit the Barco Residential Lens Calculator for further information

Optical dowser

Yes

Color correction

P7 RealColor™

Color gamut

Up to DCI (P3)

Image processing

Embedded Warp & Blend Engine

WARP

4-Corner Warp & Bow Correction via Warp Engine

Orientation

360° Rotation

Network connection

10/100 Ethernet via RJ45 connection

Integrated web server

Yes

Diagnostics

via Prospector web interface

HDR

HDR10

3D

Active Stereoscopic 3D

Additional hardware required please contact an authorized Barco representative for details

Inputs

1 x HDMI 2.0 (HDCP 2.2)

2 x HDBaseT (HDCP 1.4 - 9Gbps only)

1 x Display Port 1.2

Quad 3G / 12G SDI / BarcoLink 1 x RJ45 Ethernet

1 x RS232

1 x USB

2 x DMX (1 x Input / 1 x Output)

1 x XLR for Wired Remote

2 x 3D Sync (1 x Input / 1 x Output) Optional Upgrade: Quad DP1.2

Input resolutions

HDMI:

Up to 4,096 x 2,160 @ 24/25/30/50/60Hz

DisplayPort (Single Input):

Up to 4,096 x 2,160 @ 24/30/50/60Hz

via Optional Quad DP1.2 Input Card

DisplayPort (Layout Mode: 2 x 2) *:

Up to 1,920 x 1,080 @ 120Hz

Up to 2,048 x 1,080 @ 120Hz

DisplayPort (Layout Mode: 4 x 1) *:

Up to 960 x 2,160 @ 120Hz

* Specialist GFX cards may be required

Latency

TBD

Control

IR, RS232, IP, 12v Trigger

Driver modules available for: Crestron, Control4, RTI & Savant WiFi (Optional), XLR Wired Remote, GSM (Optional)

Power requirements

110 - 130V / 200 - 240V / 50 - 60Hz

Power consumption

110V: 1,321W Max, measured in 20-25°C / 68-77°F

230V: 1256W Max 20-25°C / 68-77°F

Power consumption will increase if ambient temperatures increses above 25°C / 77°F

Noise level (typical at 25°C/77°F)

43 dB(A)

Operating temperature

0 to 40 °C at Sea Level

Optimal Set Point: 20 °C

Operational humidity

0 to 80% (relative humidity)

BTU per hour

Max. 4,288 BTU/h @ 200 - 240V

Max. 4,516 BTU/h @ 110 - 130V

Airflow requirements

Air Inlet (from Rear w/Feet Down): Front / Top / Right

Exhaust (from Rear w/Feet Down):  Rear Clearance Requirements:

Front: 40cm

Left: 1cm

Right: 40cm

Rear: 40cm

Top: 40cm

Exhaust airflow

152 ft3/min @ 25 °C

258 m3/hour @ 25 °C Download Lens & Airflow Data Here

Dimensions (WxLxH)

Excluding Lens

540 x 725 x 355 mm

21.26 x 28.54 x 14 in.

Weight

Excluding Lens

48kg / 105bs

Shipping dimensions (WxLxH)

Including Pallet - Excluding Lens (Packaged Separately)

850 x 665 x 613 mm

33.46 x 26.18 x 24.13 in.

Shipping weight

TBD

Standard accessories

Power Cord / Remote Control

Certifications

CE, FCC Class A and cCSAus

Safety requirements

This projector may become Risk Group 3 (RG3) when an interchangeable lens with throw ratio greater than 2.3 is installed. Refer to the installation manual for further information.

Warranty

Limited 3 years parts and labor

Extendable up to 5 years
