General specifications
Digital MicroMirror Device™
3x 1.38" DC4K
Light source
Laser

Native contrast ratio
2000:1 (typical)

up to 3000:1 with HC lens

Noise Level
Projector: 51dB(A)

External cooler: 50dB(A)

@1m and 25°C ambient temperature

Heat load (max. power)
14,500 BTU/hr
3D systems
Active glasses systems and polarization systems on silver screens are supported. Color separation systems are not supported.
Dimensions (WxLxH)
projector incl. feet

760 x 1470 x 612 mm

29,92 x 57,54 x 24,09 inches

external cooler:

546 x 462 x 589 mm

21,50 x 18,19 x 23,19 inches

Native brightness
52,000 lumens (typical)
User interface
Touch Display and/or web based
Exhaust airflow
Projector: 615CFM

External cooler: 450CFM

Color gamut
DCI P3 compliant (100% of Rec.2020; when measured in xy-color coordinates)
Resolution
native 4K: 4096 x 2160
Ambient temperature
40°C / 104F max.
Power consumption
4.2kW (3W in Eco mode)
Power requirements
Single phase or triple phase 200-240V 25A

Cooler: obtains power from the projector

Notes
Cooling liquid hose and cable length: 2.5m or 5m (8.2ft or 16.4ft)

Vertical separation between cooler and projector: Maximum 3m (10ft)

** projector configuration with ICP-D; contact Barco service for the list of supported brands

Weight
projector incl.feet: 175kg/385lbs

external cooler incl. feet: 31kg/68lbs

Prime lenses
0.8; 1.01; 1.13-1.72; 1.35-1.86; 1.46-2.10; 1.65-2.60; 2.00-3.35; 2.53-4.98

High-brightness and high-contrast B-lenses compatible

Ambient humidity
85% RH max.
Long-term brightness stability
40,000 hrs @ average usage conditions
Media server
Barco Alchemy ICMP-X and other media server brands ** supported
Housing
integrated and external cooling design and patented sealed optical assembly
Safety requirements
Class 1 risk group 3
