Projection System DLP
Native Resolution XGA (1024 x 768)
Brightness* 6500 lumens (Dual lamp, Standard lens)
Contrast Ratio 2800:1
Display Color 1.07 Billion Colors
Lens
Wide Fix (5J.JAM37.011) : F=1.85, f=11.6mm
Ultra Wide (5J.JAM37.061) : F=1.96~2.3mm
Wide Zoom (5J.JAM37.021) : F=1.85~2.5, f=18.7~26.5mm
Standard (5J.JAM37.001) : F=1.64~1.86, f=26~34mm
Semi Long (5J.JAM37.051) : F=1.86~2.48, f=32.9~54.2mm
Long Zoom1 (5J.JAM37.031) : F=1.86~2.41, f=52.8~79.1mm
Long Zoom2 (5J.JAM37.041) : F=1.85~2.48, f=78.5~121.9mm

Aspect Ratio Native 4:3 (5 aspect ratio selectable)
Throw Ratio
Wide Fix (5J.JAM37.011) : 0.79:1
Ultra Wide (5J.JAM37.061) : 0.77~0.97:1
Wide Zoom (5J.JAM37.021) : 1.3~1.85:1
Standard (5J.JAM37.001) : 1.79~2.35:1
Semi Long (5J.JAM37.051) : 2.3~3.81:1
Long Zoom1 (5J.JAM37.031) : 3.71~5.57:1
Long Zoom2 (5J.JAM37.041) : 5.5~8.56:1

Image Size (Diagonal) 80"~500"
Zoom Ratio
Wide Fix (5J.JAM37.011) : Fixed
Ultra Wide (5J.JAM37.061) : 1.25:1
Wide Zoom (5J.JAM37.021) : 1.4:1
Standard (5J.JAM37.001) : 1.3:1
Semi Long (5J.JAM37.051) : 1.65:1
Long Zoom1 (5J.JAM37.031) : 1.5:1
Long Zoom2 (5J.JAM37.041) : 1.55:1

Keystone Adjustment Horizontal/ Vertical ± 30 degrees
Lamp(Normal/Economic)* 2500/ 3000 hours
Resolution Support VGA (640 x 480) to WUXGA_RB (1920 x 1200) * RB = Reduced Blanking
Horizontal Frequency 31KHz~92KHz
Vertical Scan Rate 23Hz~85Hz
Lens Shift
Wide Fix (5J.JAM37.011) : N/A
Ultra Wide (5J.JAM37.061) : 0-45% Vertical; +-10% Horizontal
Wide Zoom (5J.JAM37.021) : 0-50% Vertical; +-10% Horizontal
Standard (5J.JAM37.001) : 0-50% Vertical; +-10% Horizontal
Semi Long (5J.JAM37.051) : 0-50% Vertical; +-10% Horizontal
Long Zoom1 (5J.JAM37.031) : 0-50% Vertical; +-10% Horizontal
Long Zoom2 (5J.JAM37.041) : 0-50% Vertical; +-10% Horizontal

Interface
Computer 1 in (D-sub 15pin) x 1
Computer 2 in (5BNC, R/G/B/H/V) x 1
Monitor out (D-sub 15pin) x 1
HDMI 1.4 x 1 (Compatible with HDCP)
DVI-D in x 1 (Compatible with HDCP)
Component Video in (Y/Pb/Pr) x 1
Composite Video in (RCA) x 1
S-Video in (Mini Din 4 pin) x 1
HDBaseT x 1 (Share with LAN)
LAN (RJ45) x 1 (LAN Control)
USB (Type Mini B) N/A
12V Trigger x 1
RS232 (DB-9pin) x 1
Wired Remote x 1
IR Receiver x 2 (Front + Rear)

Dimensions(W x H x D) 505 x 194 x 385mm
HDTV Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility NTSC, PAL, SECAM
Weight 16.5KG (Without lens)
Audible Noise 39/ 34/ 35/ 32db (Dual lamp normal/ Dual lamp eco/ Single lamp normal/ Single lamp eco)
Power Supply AC 100V, 7.2A, 50 to 60Hz
AC 220-240V, 2.9A, 50 to 60Hz
Power Consumption AC 100V, 710W (Standby Power < 0.5W)
AC 220-240V, 670W (Standby Power < 0.5W)
On-Screen Display Languages ENGLISH/ 繁體中文/ FRANÇAIS/ ESPAÑOL/ DEUTSCH/ ITALIANO/ 简体中文/ 한국어/ 日本語/ РУССКИЙ/ Português/ Svenska (12 Languages)
Picture Modes Presentation/ Standard/ Game
Accessories (Included)
Remote Control without Battery
6 Segments Color Wheel
Power Cord (by region)
User Manual CD
Quick Start Guide
Warranty Card (by region)
VGA (D-sub 15pin) Cable

Accessories (Optional)
Spare Lamp Kit : 5J.JAM05.001
Ceilling Mount : 5J.JCY10.001
Optional Lens :
Wide Fix (5J.JAM37.011)
Ultra Wide (5J.JAM37.061)
Wide Zoom (5J.JAM37.021)
Standard (5J.JAM37.001)
Semi Long (5J.JAM37.051)
Long Zoom1 (5J.JAM37.031)
Long Zoom2 (5J.JAM37.041)
