Native resolution

4K UHD 3840 x 2160 (16:9)

Backlight

Edge-lit LED

LED lifespan

30,000 hours to 50% brightness

Display orientation

Landscape

Pixel pitch (WxH)

0.372 x 0.372mm

Bezel size (bottom/side/top)

TBD

Brightness (typical) - (cd/sq m)

450 nits

Contrast ratio (typical)

1,200:1

Viewing angle (CR 10:1)

178 degrees h/v

Refresh rate

60Hz

Response time (typical)

8ms

Color space typical (CIE 1931)

75%

Display colors

10 bit, 1.07 billion

Video inputs

4 x HDMI (Ver 2.0b, HDCP 2.2)

2 x DisplayPort Ver 1.2 (up to 3840 x 2160 @ 60 Hz)

OPS

Video outputs

None

Audio inputs

3.5mm headphone jack

Audio outputs

3.5mm headphone jack

Control inputs

RS-232 via D-Sub9

LAN via RJ45

IR wire extender

USB-A2.0 for service

​​Power input rating

100-240 VAC @ 50/60Hz

Power consumption

TBD without OPS

TBD maximum without OPS

0.5W standby without OPS

Operating temperature

32-104°F (0-40°C)

Storage temperature

-4-140°F (-20-60°C)

Operating humidity

20-90% RH non-condensing

​Physical size (panel only)

(WxHxD): 57.8 x 33.2 x 2.7" (1469 x 844 x 68mm)

Weight

TBD

Mounting

TBD

Runtime

Recommended for 18/7 operation featuring a reliable power supply*

Features

Commercial-grade LCD with edge-lit LED backlight

OPS slot

Anti-glare treatment

2 x 15W speakers

HDMI-CEC

Source switching for failover

No RF capability

4 window multi-source UHD viewing (Quadview, PiP, PBP)

MEMC

Crestron Connected

Accessories

Panel ships with HDMI 2.0 Cable, RS232 Cable, Remote Control with batteries, IR receiver

Warranty

Three years parts and labor limited warranty

*Avoid static images for extended periods. Refer to the user manual for additional runtime ​guidance.

Content and operating conditions can affect the useful life of the product. Please refer to the product documentation.

Performance specifications are typical. Due to constant research, specifications are subject to change without notice.
