• 3.5" (2 Rack Units) 4" with feet (88.9mm or 101.6mm with feet)

• 19" (482.6mm)

• 12" (304.8mm)

• 16lbs (7.3kg)

• 100V to 240V AC 50/60Hz, 100W

Video

• 2 x HDMI • 1 x HDMI / DVI-I
• 1 x HDMI / DVI-D (Support for HDCP and embedded audio)
• 2 x Component (3 x RCA)
• VGA (HD15)

Audio

• 16 x DCI-AES Digital, 8 Pairs (DB-25)
• DCI-AES ALT1 Pairs 1-4 (RJ-45)
• DCI-AES ALT2 Pairs 5-8 (RJ-45)
• 8 x Balanced analog (DB-25)
• 3 x Analog (RCA)
• 3 x Coax SPDIF (RCA)
• 3 x Optical SPDIF (Toslink)
• 2 x HDMI (Support for embedded audio)
• Microphone (XLR)

VIdeo

• HDMI L / DVI-D (Left eye in dual stream 3D mode)
• HDMI R / DVI-D (Right eye in dual stream 3D mode)

Audio

• 8 x Balanced analog (DB-25)
• L (Left) Low, balanced analog, (3 pin Phoenix)
• C (Center) Low, balanced analog, (3 pin Phoenix)
• R (Right) Low, balanced analog, (3 pin Phoenix)
• Aux 1 / LS (Left Surround) Low, balanced analog, (3 pin Phoenix)
• Aux 2 / RS (Right Surround) Low, balanced analog, (3 pin Phoenix)
• HI (Hearing Impaired), balanced analog, (3 pin Phoenix)
• VI/N (Visually Impaired/Narrative), balanced analog, (3 pin Phoenix)
• Booth monitor, unbalanced analog (RCA)
• Headphone (TRS)

• Ethernet (RJ-45) for IP control and setup
• RS-232 (DB-9)
• 8 contact closure inputs (16 pin Phoenix)
• 4 dry relay outputs (8 pin Phoenix)
