Specyfikacja techniczna:


Brightness

7,600 ISO lumens
7,000 ANSI lumens
Color wheel

4 segment (RGBY) - 2X or 3X speed
Contrast (nominal)

Full on/off (Christie RealBlack enabled): 2,000,000:1
Dynamic contrast: 5000:1
Full on/off (Christie RealBlack disabled): 1200:1
ANSI 250:1
Display

Type

1 x 0.66" DMD
Resolution

4K UHD; 4.15MP; 2716x1528 (WQXGA+) DMD
3840 x 2160 (8,294,400 pixels) 16:9
Illumination system

Type

Laser phosphor with Christie BoldColor Technology
Typical lifetime

20,000 hours to 50%
Signal inputs

Standard

HDMI x 2 (HDMI 2.0b, HDCP 2.1 Compliant)
3GSDI x 1 (BNC)
DVI-D x 1 (digital only)
DisplayPort x 1 (versions 1.2)
USB x 1 (Type A)
Image Viewer or Wi-Fi® dongle (optional)
HDBaseT (RJ45 x 1)
Optional

Terra SDVoE (optional input card)
12G SDI (optional input card)
Note: HDBaseT comes standard but occupies 1 of the 2 optional input slots
3D

HDMI 1.4, HDBaseT – frame packed, top/bottom, side-by-side (up to 120Hz output)
3D sync in (BNC) – for genlocking projectors
3D sync out (BNC) – for genlocking projectors, or controlling emitters​
Signals

Standard video signals up to 4096 x 2160 @ 60Hz (over a single cable; HDMI 2.0 or DP 1.2)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel clock

Maximum input pixel rate 600 Mpix/s (supports 4096 x 2160 @ 60Hz / 3840 x 2160 @ 60Hz over HDMI & DP)
Maximum input pixel rate 300 Mpix/s (supports 1920 x 1080 @ 120Hz over DVI)
Minimum input pixel rate 27 Mpix/s (supports 480i @ 60Hz & 576i @ 50Hz)
Scan rates

Horizontal: 15 kHz to 91 kHz
Vertical: 24 Hz to 85 Hz
Signal outputs

Monitor out (loop through)

3GSDI x 1 (BNC)
DVI-D x 1 (Digital out)
Control and networking

RS232 In
Control via HDBaseT
Ethernet (10/100) RJ45
Built-in backlit keypad
Wired remote control (3.5mm stereo) - loop out available for daisy chaining
Accessories

Standard

IR remote w/ wired remote jack (wire not included)
AC line cords for projector head
User manual
Optional

Christie One Rigging Frame
Lens adapter for E Series lenses
1DWUSB-BGN (wireless dongle for video and control)
HS fog filter covers + filters (order once per projector then only filters refills)
HS fog filter refills (1 set)
Christie One Mount Plus
One Mount Extender Rod
One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
Replacement remote control
Lens mount

Boresight adjustable
Motorized horizontal and vertical lens offset (memory available)
Motorized zoom and focus adjustment (memory available for full ILS lenses)
Lens options

Lenses

0.85-1.02:1 zoom lens
1.20-1.73:1 zoom lens
1.2-1.5:1 zoom lens (full ILS)
1.5-2.0:1 zoom lens (full ILS)
2.0-4.0:1 zoom lens (full ILS)
4.0-7.0:1 zoom lens (full ILS)
Offsets (Full ILS lenses)

+/- 120% vertical
+/- 50% horizontal
Offsets 0.84-1.02:1

Offsets 1.02-1.36:1

+51 / -53% vertical
+11 / -50% horizontal
Power requirements

Operating voltage

Normal: 100-240 VAC @ 50/60Hz
Power consumption

Maximum power consumption: 1070W
ECO1 mode (80%): 865W
ECO2 mode (50%): 540W
Operating current

Normal mode: 9.0A ±15% (120 VAC), 4.8A ±15% (220 VAC)
ECO1 mode: 7.2A ±15% (120 VAC), 3.9A ±15% (220 VAC)
ECO2 mode: 4.5A ±15% (120 VAC), 2.45A ±15% (220 VAC)
Dissipation

Normal mode: 3651 BTU/hr
ECO1 mode: 2951 BTU/hr
ECO2 mode: 1842 BTU/hr
Audible noise

Typical: 39dB(A)
Eco mode: 33dB(A)
Physical specs

Dimensions

(L x W x H) 23.6 x 20.5 x 8.4" (600 x 520 x 214mm) without feet
Weight (without lens)

79.4 lb (36 kg)
Shipping dimensions

(L x W x H) 35.6 x 29.9 x 14.8" (905 x 760 x 365mm)
Shipping weight

99 lb (45 kg)
Operating environment

Temp: 0 to 40° C (32 to 104° F)
Humidity: 0 - 85% non-condensing
Regulatory

Contact Christie for the timing of certifications:

UL/CSA/IEC 60950-1
FCC Class A
CE
FDA
CCC
KC
PSE
CU
SABS
BIS
VCCI
RCM
Ukr
TER
SASO
This product conforms to all relevant European directives, standards, safety, health and environmental concerns

RoHS
REACH
WEEE
Limited warranty

Three years parts and labor on the projector
Three years or 15,000 hours parts and labor on the illumination system*
Contact an authorized Christie representative for full details of our limited warranty
*Please reference the Christie Standard Limited Warranty document for details.
