Brightness

11,250 lumens (compliant with ISO 21118 std)
11,000 centre lumens
10,500 ANSI lumens
Contrast

5000:1 (Dynamic Aperture Enabled)
1200:1 Full On/Off
250:1 ANSI
Colour Wheel

6-segment (RGBCYW)
Display
Type

1-chip 0.95" DMD
Native Resolution

1920 x 1080 HD (2,073,600 pixels) 16:9
Lamp
Type

2 x 465W (003-005237-XX)
Life

High power: 1500 hours @ 465W
Low power: 2000 hours @ 370W
​Input
Standard

HDMI x 2 (One on side panel, one on bottom of projector, independently selectable)
3GSDI x 1 (BNC)
DVI-D x 1 (Digital only)
Display Port x 1
HD15 x 1
RGBHV/Component (5 BNC)
Composite Video x 1 (BNC)
S-Video x 1 (mini DIN)
Component Video (RCA)
USB x 1 (Type B mini) - Display over USB
USB x 1 (type A) - Image Viewer or WiFi Dongle (optional)
HDBaseT (RJ45 x 1)
RJ45 x 1 (ChristiePresenter over wired network connection)
3D
HDMI input only
3D Sync In (BNC) - for genlocking projectors
3D Sync Out (BNC) - for genlocking projectors or controlling emitter or polarizer
Signals

HDTV formats VGA through to WUXGA (19200 x 1200)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel Clock

162MHz
Scan Rates

Horizontal: 15kHz to 100kHz
Vertical: 24Hz to 85Hz
Output
Standard

HD15 x 1
Control & Networking

RS232 In
Control via HDBaseT
Ethernet (10/100) RJ45 with ChristieNET connectivity
Built-in backlit keypad
Wired remote control (3.5mm stereo) - Loop out available for daisy chaining
Accessories
Standard

IR Remote w/ wired remote jack (wire not included)
Coarse Dust Filters - 3 Pack (Not mandatory for standard use)
AC Line cords for projector Head
User Manual
Optional

Rigging/Stacking Frame
Lens Adapter for E Series Lenses
1DWUSB-BGN (Wireless Dongle for video and control)
Fog Filters - 3 Pack
Ceiling Mount
Ceiling Mount Extension Rod
Replacement Remote Control
​Lens mount
​Tool-free lens insertion system
Boresight adjustable
Motorised horizontal and vertical lens offset (Memory Available)
Motorised zoom and focus adjustment (Memory Available for Full ILS lenses)
​Lens options
​Lenses

0.84-1.02:1 Zoom Lens (No Zoom/Focus Memory) - Adapted 1.2-1.5:1 E Series Lens
1.02-1.36:1 Zoom Lens (No Zoom/Focus Memory) - Adapted 1.5-2.0:1 E Series Lens
1.2-1.5:1 Zoom Lens (Full ILS)
1.5-2.0:1 Zoom Lens (Full ILS)
2.0-4.0:1 Zoom Lens (Full ILS)
Offsets (Full ILS lenses)

+/- 133% Vertical (+/- 720 pixels)
+/- 50% Horizontal (+/- 480 pixels)
Power requirements
Operating Voltage

100-240V AC @ 50/60Hz
Current Rating

5.5A max (220V), 12A max (110V)
Power Consumption

Normal Mode: 1100W max (220V) 1180W max (110V)
Eco Mode: 880W max (220V), 950W (110V)
Thermal Dissipation

3753 BTU/hr max, 3003 BTU/hr Eco Mode
Dimensions
Dimensions (LxWxH) (without lens and feet)

604 (L) x 520 (W) x 182 (H) mm
23.78 (L) x 20.47 (W) x 7.16 (H) in.
Net Weight (without lens)

23.8kg (52.5 lbs)
Shipping Dimensions

790 (L) x 666 (W) x 352 (H) mm
31.10 (L) x 26.22 (W) x 13.86 (H) in.
Shipping Weight

28.5kg (62.8lbs)
Operating Environment
Noise

Typical: 465W: 40dB(A)
Eco Mode: 370W: 37dB(A)
Temperature

32-104°F (0-40°C)
Humidity

10-85% non-condensing
Regulatory
UL/CSA/IEC 60950-1
FCC Class A
CE
CCC
KC
PSE
CU
SABS
BIS
VCCI
RCM
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, REACH, WEEE

Limited warranty
3 years parts and labour (including light engine)
Lamp: 500 hours or one year (whichever comes first)
Contact an authorised Christie representative for full details of our limited warranty
