Specyfikacja techniczna:


Brightness

17,400 ISO lumens
15,500 ANSI lumens
Color wheel

4 segment (RGBY) - 2X or 3X speed
Contrast (nominal)

Full on/off (Christie RealBlack enabled): 2,000,000:1
Dynamic contrast: 5000:1
Full on/off (Christie RealBlack disabled): 1200:1
ANSI 250:1
Display

Type

1 x 0.96" DMD
Native resolution

1920 x 1200 (2,304,000 pixels) 16:10
Illumination system

Type

Laser phosphor with Christie BoldColor Technology
Typical lifetime

20,000 hours to 50%
Signal inputs

Standard

HDMI x 2 (one on rear panel, one on bottom of projector, independently selectable)
3GSDI x 1 (BNC)
DVI-D x 1 (digital only)
HD15 x 1
USB x 1 (type A) - image viewer or WiFi dongle (optional)
HDBaseT (RJ45 x 1)
3D

HDMI 1.4, HDBaseT - frame packed, top/bottom, side-by-side
Up to 120Hz output
3D Sync In (BNC) - for genlocking projectors
3D Sync Out (BNC) - for genlocking projectors or controlling emitters
Signals

HDTV formats VGA through to WUXGA (1920 x 1200)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel clock

162 MHz
Scan rates

Horizontal: 15 kHz to 91 kHz
Vertical: 24 Hz to 85 Hz
Signal outputs

Monitor out (loop through)

3GSDI x 1 (BNC)
HDMI x 1 (HDMI out)
Control and networking

RS232 In
Control via HDBaseT
Ethernet (10/100) RJ45
Built-in backlit keypad
Wired remote control (3.5mm stereo) - loop out available for daisy chaining
12VDC trigger at 200mA (ID:2.5mm)
Accessories

Standard

IR remote w/ wired remote jack (wire not included)
AC line cords for projector head
User manual
Optional

Christie One Rigging Frame
Lens adapter for E Series lenses
1DWUSB-BGN (wireless dongle for video and control)
HS fog filter covers + filters (order once per projector then only filters refills)
HS fog filter refills (1 set)
Christie One Mount Plus
One Mount Extender Rod
One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
Replacement remote control
Lens mount

Boresight adjustable
Motorized horizontal and vertical lens offset (memory available)
Motorized zoom and focus adjustment (memory available for full ILS lenses)
Lens options

Lenses

0.84-1.02:1 zoom lens (no zoom/focus memory) - adapted 1.2-1.5:1 E Series lens
1.02-1.36:1 zoom lens (no zoom/focus memory) - adapted 1.5-2.0:1 E Series lens
1.2-1.5:1 zoom lens (full ILS)
1.5-2.0:1 zoom lens (full ILS)
2.0-4.0:1 zoom lens (full ILS)
4.0-7.0:1 zoom lens (full ILS)
Offsets (Full ILS lenses)

+/- 120% vertical
+/- 50% horizontal
Offsets 0.84-1.02:1

+37 / -60% vertical
+15 / -44% horizontal
Offsets 1.02-1.36:1

+51 / -53% vertical
+11 / -50% horizontal
Power requirements

Operating voltage

Normal: 100-240VAC @ 60/50 Hz
Power consumption

Normal mode: 1250W +/-15% (220V), 1300W +/-15% (110V)
ECO1 mode: 1020W +/-15% (220V), 1050W +/-15%(110V)
ECO2 mode: 700W +/-15% (220V), 700W +/-15%(110V)
Operating current

Normal mode: 6.0A ±15% (220 VAC), 11.9A ±15% (110 VAC)
ECO1 mode: 4.7A ±15% (220 VAC), 9.6A ±15% (110 VAC)
ECO2 mode: 6.5A ±15% (220 VAC), 3.2A ±15% (110 VAC)
Dissipation

Normal mode: 4450 BTU/hr
ECO1 mode: 3600 BTU/hr
ECO2 mode: 2450 BTU/hr
Audible noise

Typical: 45dB(A)
Eco mode: 39dB(A)
Physical specs

Dimensions

(L x W x H) 26.65 x 23.46 x 7.99" (677 x 596 x 203mm) without feet
Weight (without lens)

93.7 lb (42.5 kg)
Shipping dimensions

(L x W x H) 36.34 x 33.19 x 20.20" (923 x 843 x 513mm)
Shipping weight

119 lb (54 kg)
Operating environment

Temp: 0 to 40° C (32 to 104° F)
Humidity: 0 - 85% non-condensing
Regulatory

Contact Christie for the timing of certifications:

UL/CSA/IEC 60950-1
FCC Class A
CE
FDA
CCC
KC
PSE
CU
SABS
BIS
VCCI
RCM
Ukr
TER
SASO
This product conforms to all relevant European directives, standards, safety, health and environmental concerns

RoHS
REACH
WEEE
Limited warranty

Three years parts and labor on the projector
Three years or 15,000 hours parts and labor on the illumination system*
Contact an authorized Christie representative for full details of our limited warranty
*Please reference the Christie Standard Limited Warranty document for details.
