25,000 centre lumens
2000:1 contrast ratio
Brightness
25,000 centre [22,500 ANSI] lumens - 3.0kW lamp CDXL-30SD
18,000 centre [16,000 ANSI] lumens - 3.0kW lamp CDXL-30
10,000 centre [9,000 ANSI] lumens - 2.0kW lamp CDXL-20
Display
3-chip 1.38" DMD
Native 4K (4096 x 2160)
Lamp
Xenon bubble
3.0kW CDXL-30SD - 1,500 hours
3.0kW CDXL-30 - 2,500 hours
2.0kW CDXL-20 - 3,500 hours
Signals
Standard

2x Dual 3G HD-SDI input card
2x Twin display port input card
Optional

Dual link DVI input card
Twin HDMI input card
Signal inputs

Accepts 4K (4096x2160) and Quad HD (3840x2160)

4 x DisplayPort 1.1a
4K/Quad HD - 24 to 60Hz 4:4:4 8-/10-bit
4K/Quad HD - 24 to 60Hz 4:2:2 8-/10-/12-bit
2 x DisplayPort 1.1a
4K/Quad HD - 24 to 60Hz 4:4:4 8-/10-bit
4 x HD SDI
4K/Quad HD - 24 to 30Hz 4:4:4 12-bit (4 x 3G HD-SDI)
4K/Quad HD - 24 to 30Hz 4:2:2 12-bit (4 x 3G HD-SDI)
4K/Quad HD - 24 to 30Hz 4:2:2 10-bit (4 x HD-SDI)
4K/Quad HD - 50 to 60Hz 4:2:2 10-bit (4 x 3G HD-SDI)
4 x DVI
4K/Quad HD - 24 to 60Hz RGB 8-bit
2 x DVI (Dual Link)
4K/Quad HD - 24 to 60Hz RGB 8-bit
Signal outputs - loop-out

Dual 3G HD-SDI input card, twin DisplayPort input card
Control and networking
RS-232
Ethernet (10/100) RJ45 with ChristieNET™ connectivity
Detachable LCD control module
Lens mount
Type

Tool-free lens insertion system
Boresight adjustable
Motorised

Horizontal and vertical offset
Focus
Zoom
Lenses
Fixed

0.72:1 (no offset)
1.0:1 (Offset: Vertical: ± 29% Horizontal: 9%)
Zoom

1.13-1.31:1 (Offset: Vertical: ± 56% Horizontal: 19%)
1.31-1.63:1 (Offset: Vertical: ± 13% Horizontal: 4%)
1.63-2.17:1 (Offset: Vertical: ± 13% Horizontal: 4%)
1.98-2.71:1 (Offset: Vertical: ± 13% Horizontal: 4%)
2.71-3.89:1 (Offset: Vertical: ± 13% Horizontal: 4%)
3.89-5.43:1 (Offset: Vertical: ± 13% Horizontal: 4%)
5.43:1 -7.69:1 (Offset: Vertical: ± 56% Horizontal: 19%)
Accessories
Standard

Detachable LCD control module
AC line cord for projector head
CDXL-30SD lamp
Optional

CDXL-20 lamp
CDXL-30 lamp
Heat extraction fan kit (required when operating the projector)
Rack mount pedestal
Replacement air filter for the light engine
Replacement air filter for the liquid cooling radiator
Lamp adapter kit for CDXL-20
Christie Twist 4K (limited to 30 frames per second)
Power requirements
Projector head
Operating voltage: Single phase 200-240V AC @50/60Hz
Operating current: 23A max at 200V
Ballast
Integrated ballast and projector head
Dimensions
Size

(LxWxH): 51.1 x 25.5 x 19.0" (1298 x 648 x 483mm)
Shipping size

(LxWxH): 60.4 x 36.0 x 28.5" (1535 x 914 x 724mm)
Weight

273lbs (124kg)
Shipping weight

344lbs (156kg)
Operating environment
Operating temperature: 50–95°F (10–35°C)
Humidity (noncondensing): 20–80%
Regulatory approvals
This product conforms to these regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):

Directives:

(EC) 2011/65/EU (RoHS)
2012/19/EU (WEEE)
Regulations:

(EC) No. 1907/2006 (REACH)
CAN/CSA C22.2 No. 60950-1
UL 60950-1
IEC 60950-1
EN 60950-1
FCC, Part 15, Subpart B, Class A
EN55022/CISPR22 Class A
EN55024/CISPR24
The product is designed to comply to the rules and regulations required for the product to be sold in various regional markets, including: USA/Canada, EU, Norway, Australia/New Zealand, Kuwait, China, Korea, Japan, Mexico, Ukraine, Russia, South Africa, and Saudi Arabia.

Limited warranty
Projector: 3 years parts and labour (including light engine)
Lamp: Contact an authorised Christie representative for the full details of our limited warranty.

Due to constant research, specifications and features are subject to change without notice.

1 User-replaceable bulb
2 Some features may not be functional on initial product shipments but will be enabled by software upgrade when available.
