35,000 centre lumens
2000:1 contrast ratio
Brightness
35,000 centre [32,500 ANSI] lumens - 6.0kW lamp
29,000 centre [27,000 ANSI] lumens - 4.5kW lamp
19,500 centre [18,000 ANSI] lumens - 3.0kW lamp
13,000 centre [12,000 ANSI] lumens - 2.0kW lamp
Display
3-chip 1.38" DMD
Native 4K (4096 x 2160)
Lamp
Xenon bubble, user-replaceable bulb1
6.0kW lamp CDXL-60 - 750 hours
4.5kW lamp CDXL-30 - 900 hours
3.0kW lamp CDXL-20 - 2,500 hours
2.0kW lamp CDXL-20 - 3,500 hours
Signals Standard
2x Dual 3G HD-SDI input card
2x Twin display port input card
Optional

Dual link DVI input card
Twin HDMI input card
Signal inputs

Accepts 4K (4096x2160) and Quad HD (3840x2160)
4 x DisplayPort 1.1a
4K/Quad HD - 24 to 60Hz 4:4:4 8-/10-bit
4K/Quad HD - 24 to 60Hz 4:2:2 8-/10-/12-bit
2 x DisplayPort 1.1a
4K/Quad HD - 24 to 60Hz 4:4:4 8-/10-bit
4 x HD SDI
4K/Quad HD - 24 to 30Hz 4:4:4 12-bit (4 x 3G HD-SDI)
4K/Quad HD - 24 to 30Hz 4:2:2 12-bit (4 x 3G HD-SDI)
4K/Quad HD - 24 to 30Hz 4:2:2 10-bit (4 x HD-SDI)
4K/Quad HD - 50 to 60Hz 4:2:2 10-bit (4 x 3G HD-SDI)
4 x DVI
4K/Quad HD - 24 to 60Hz RGB 8-bit
2 x DVI (Dual Link)
4K/Quad HD - 24 to 60Hz RGB 8-bit
Signal outputs - loop-out

Dual 3G HD-SDI input card, twin DisplayPort input card
Inputs, control and networking
RS-232
Ethernet (10/100) RJ45 with ChristieNETTM connectivity
Detachable LCD control module
Lens mount
Type

Tool-free lens insertion system
Boresight adjustable
Motorised

Horizontal and vertical offset
Focus
Zoom
Lenses
Fixed

0.72:1 (no offset)
1.0:1 (Offset: Vertical: ± 29% Horizontal: 9%)
Zoom

1.13-1.31:1 (Offset: Vertical: ± 56% Horizontal: 19%)
1.31-1.63:1 (Offset: Vertical: ± 13% Horizontal: 4%)
1.63-2.17:1 (Offset: Vertical: ± 13% Horizontal: 4%)
1.98-2.71:1 (Offset: Vertical: ± 13% Horizontal: 4%)
2.71-3.89:1 (Offset: Vertical: ± 13% Horizontal: 4%)
3.89-5.43:1 (Offset: Vertical: ± 13% Horizontal: 4%)
5.43:1-7.69:1 (Offset: Vertical: ± 56% Horizontal: 19%)
Accessories
Standard

Detachable LCD control module
AC line cord for projector head
Detached 7kW low-ripple switch mode lamp ballast (required to operate projector)
CDXL-60 lamp
Optional

CDXL-20 lamp
CDXL-30 lamp
CDXL-45 lamp
Heat extraction fan kit (required when operating the projector)
Rack mount pedestal
Replacement air filter for the light engine
Replacement air filter for the liquid cooling radiator
Lamp adapter kit for CDXL-20
Christie Twist 4K (limited to 30 frames per second)
Power requirements
Projector head

Operating voltage: Single phase 200-240V AC @50/60Hz
Operating current: 7A max at 200V
Ballast

Type: detached, 7kW low-ripple, switch-mode lamp ballast
Operating voltage: 3-phase 200-230V AC @ 50/60Hz
Operating current: 38A per phase max
Operating voltage: 3-phase 380-415V AC @ 50/60Hz
Operating current: 26A per phase max
Dimensions
Size

Projector head (LxWxH): 51.1 x 25.5 x 19.0" (1298 x 648 x 483mm)
Ballast (LxWxH): 21 x 18 x 21" (533 x 457 x 533mm)
Shipping size

Projector head (LxWxH): 60.4 x 36.0 x 28.5" (1535 x 914 x 724mm)
Ballast (LxWxH): 28.0 x 25.0 x 31.5" (710 x 635 x 800mm)
Weight

Projector head 251lbs (114kg)
Ballast 89lbs (40.5kg)
Shipping weight

Projector head 322lbs (146kg)
Ballast 135lbs (62kg)
Operating environment
Operating temperature: 50-95°F (10-35°C)
Humidity (noncondensing): 20-80%
Regulatory approvals
This product conforms to these regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):

Directives:

(EC) 2011/65/EU (RoHS)
2012/19/EU (WEEE)
Regulations:

(EC) No. 1907/2006 (REACH)
CAN/CSA C22.2 No. 60950-1
UL 60950-1
IEC 60950-1
EN 60950-1
FCC, Part 15, Subpart B, Class A
EN55022/CISPR22 Class A
EN55024/CISPR24
The product is designed to comply to the rules and regulations required for the product to be sold in various regional markets, including: USA/Canada, EU, Norway, Australia/New Zealand, Kuwait, China, Korea, Japan, Mexico, Ukraine, Russia, South Africa, and Saudi Arabia.

Limited warranty
Three years parts and labour (including light engine)
Contact an authorised Christie representative for the full details of our limited warranty.
