Brightness
10,000 (ISO)
8,800 (ANSI)
Color wheel
4 Segment (RGBY) - 2X or 3X speed
Contrast (nominal)
Full On/Off (Christie Real Black Enabled): 300,000:1
Dynamic Contrast: 6,000:1
Full On/Off (Christie Real Black Disabled): 1,200:1
ANSI: 250:1
Display
1 x 0.65" DMD
Resolution
1920 x 1080 (2,073,600 pixels) 16:9
Illumination type
Laser Phosphor with Christie BoldColor Technology
Illumination lifetime
20,000 hours
Signal inputs
Standard

HDMI x 2 (One on rear panel, one on bottom of projector, independently selectable)
3GSDI x 1 (BNC)
DVI-D x 1 (Digital only)
HD15 x 1
USB x 1 (Type B mini) - Display over USB
USB x 1 (type A) - Image Viewer or WiFi Dongle (optional)
HDBaseT (RJ45 x 1)
RJ45 x 1 (ChristiePresenter over wired network connection)
3D

HDMI 1.4, HDBaseT - Frame Packed, Top/Bottom, Side By Side
Up to 120Hz output
3D Sync In (BNC) - for genlocking projectors
3D Sync Out (BNC) - for genlocking projectors or controlling emitter or polarizer
Signals

HDTV formats VGA through to WUXGA (1920 x 1200)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel clock

162MHz
Scan rates

Horizontal: 15 kHz to 91 kHz
Vertical: 24 Hz to 85 Hz
Signal outputs
HDMI x 1
3GSDI x 1 (BNC)
Control & networking
RS232 In
Control via HDBaseT
Ethernet (10/100) RJ45 with ChristieNET connectivity
Built-in Backlit Keypad
Wired Remote Control (3.5mm stereo) - Loop out available for daisy chaining
Accessories
Standard

IR Remote w/ wired remote jack (wire not included)
AC Line cords for projector
Rear Input/Keypad Panel Cover
User Manual
Optional

QwikRig Rigging Frame
Christie One Mount Plus
One Mount Extender Rod
One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
Wireless Dongle
Lens mount
Boresight adjustable
Motorized horizontal and vertical lens offset
Motorized zoom and focus adjustment
Lens options
Lens 0.36 (120"), Ultra short throw lens, 700/850/1075-GS
Lens 0.75-0.95 Zoom G/GS
Lens 0.95-1.22 Zoom G/GS
Lens Zoom HP G/GS 1.22-1.52 (All G & GS)
Lens 1.52-2.89 Zoom G/GS
Lens 2.9-5.50:1 Zoom G/GS
Lens offsets (max)
+/- 60% Vertical
+/- 15% Horizontal
Power requirements
Operating voltage

Normal: 100-240 VAC @ 50/60 Hz (w/ 15A fuse)
Power consumption

Normal Mode: 1070W
Operating current

Normal Mode: 10A (100V-240V)
Audible Noise (typical 2x Wheel Speed)
32dB(A) Eco2 Mode
35dB(A) Normal Mode
Physical dimensions
(L x W x H)
19.2 x 22.2 x 7.6"
480 x 555 x 190mm w/o feet or lens
Physical weight
54.9 lb (24.9 kg) w/o lens
Shipping dimensions
(L x W x H)
24.07 x 30.4 x 14.9"
599 x 759 x 373mm
Shipping weight
69.9 lb (31.7 kg)
Operating environment
0 to 40° C (32 to 104° F), 0-2500 ft altitude
0 to 30° C (32 to 86° F), 5,000-10,000 ft altitude
Humidity: 0 - 85% non-condensing
Regulatory
Contact Christie for timing of certifications: UL/CSA/IEC 60950-1, FCC Class A, CE, FDA, CCC, KC, PSE, CU, SABS, BIS, VCCI, RCM, Ukr, TER, SASO
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, REACH, WEEE
Limited warranty
3 years parts and labor on the projector
3 years or 15,000 hours parts and labor on the illumination system*
Contact an authorized Christie representative for full details of our limited warranty
*Please reference the Christie Standard Limited Warranty document for details.
