Brightness
5000 ANSI (typical)
Contrast
1200:1
Full on/full off: Zero light output on full black field with Christie RealBlack™ enabled
Display
1-chip 0.65" DMD
Resolution
1920 x 1080 (16:9)
Illumination
Solid State (Laser Phosphor)
Lamp Life
20,000 hrs
Inputs
HDMI x 1
DVI-D x 1 (digital only)
DisplayPort x 1
HD15 x 1
Composite video x 1 (RCA)
S-Video x 1 (mini DIN)
Component video (Y/Pb/Pr)
USB x 1 (type B mini) - display over USB
USB x 1 (type A) - image viewer or WiFi dongle (optional)
RJ45 x 1
Signals
HDTV formats VGA through to WUXGA (1920 x 1200)
Pixel clock
162MHz
Scan rates
Horizontal 15kHz to 100kHz
Vertical: 24Hz to 85Hz
Monitor out
HD15 x 1
Networking
RS-232 in
Ethernet (10/100) RJ45 with ChristieNET connectivity
Built-in backlit keypad
Compatible with Crestron Connected, AMX Discovery
Standard accessories
IR remote w/ wired remote jack (wire not included)
AC line cord for projector head
User manual
Optional accessories
1DWUSB-BGN (wireless dongle for video and control) (133-113106-XX)
Warp module (133-111104-XX)
Cable cover (140-106108-XX white | 140-106119-XX black)
Portrait side cover (140-108100-XX white | 140-108111-XX black)
Christie One Mount (108-506102-XX)
Lens mount
Tool-free lens insertion system
Boresight adjustable
Motorised horizontal and vertical lens offset
Motorised zoom and focus adjustment
Lenses
0.95-1.22:1 (HD/WU) zoom lens (140-101103-XX)
1.22-1.53:1 (HD/WU) zoom lens (140-100102-XX)
1.52-2.92:1 (HD/WU) zoom lens (140-102104-XX)
2.9-5.50:1 (HD/WU) zoom lens (140-107109-XX)
Offsets
+/-120% vertical (+/-648 pixels)
+/-30% horizontal (+/-288 pixels)
Power
voltage: 100-240V AC @ 50/60Hz
consumption: 520W max, 340W eco mode
current: 6.0A max
Dissipation
1774 BTU/hr max, 1160 BTU/hr Eco Mode
Audible noise
Standard Mode: 38dB(A), Eco Mode: 34dB(A)
Dimensions
(L x W x H)
physical: 19.88 x 18.31 x 7.48" (505 x 465 x 190 mm) without feet
shipping: 31.89 x 23.43 x 13.43" (810 x 595 x 341mm)
Weight
physical: 35.0lbs (15.9kg)
shipping: 47.8lbs (21.7kg)
Operating environment
temperature: 5 to 40°C (40 to 104°F)
humidity: 0 to 90% non-condensing
Regulatory
UL/CSA/IEC 60950-1
FCC Class A, CE, CCC, KC, EAC, PSE, C-tick, CU, SABS, BIS, VCCI, RCM and South Africa
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, REACH, WEEE
Warranty
3 years on the projector
3 years or 15,000 hours on the illumination system*
