Brightness
6,200 centre (5,950 ANSI) lumens
Contrast
4800:1 (dynamic contrast enabled)
1200:1 (full on/ full off)
250:1 (ANSI)
Display technology and resolution
1-chip 0.65" DMD
1920 x 1080 HD
Lamp
465W NSH
2000 hrs minimum @ 465W
2500 hrs typical @ 360W
Inputs
Standard

1x HDMI
1x DVI-D (digital only)
1x DisplayPort
1x HD15
1x RCA (composite video)
1x S-Video (mini DIN)
Component video (RCA)
1x USB (type B mini) - display over USB
1x USB (type A) - image viewer or Wi-fi dongle (optional)
1x RJ45
Signals

HDTV formats VGA through to WUXGA (1920 x 1200)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel clock
162 MHz
Scan rates
Horizontal: 15kHz to 100kHz
Vertical: 24kHz to 85kHz
​Outputs
​1x HD15
Control and networking
RS232 in
Ethernet (10/100) RJ45 with ChristieNET™ connectivity
Build-in backlit keypad
Wired remote control (3.5mm stereo) - wire not included
Optical system
Tool-free lens insertion system
Boresight adjustable
Motorized zoom, focus and lens offset
Lenses
1.22-1.52:1 (HD) zoom lens (included)
1.52-2.89:1 (HD) zoom lens (optional)
2.90-5.50:1 (HD) zoom lens (optional)
0.95-1.22:1 (HD) zoom lens (optional)
Offsets
Vertical: +/-120% (+/- 648 pixels)
Horizontal: +/-20% (+/-192 pixels)
Standard accessories
IR remote w/ wired remote jack (wire not included)
AC line cord for projector head
User manual
Optional accessories
1DWUSB-BGN (Wireless dongle)
Warp module
Cable cover
Ceiling mount
Ceiling mount extension
Power requirements
Operating voltage: 100V AC to 240V AC @ 50/60 Hz
Operating current: 6.5A max
Power consumption: 580W max, 450W eco mode
Dissipation: 1979 BTU/hr max, 1535 BTU/hr eco mode
Dimensions and weight
Size: (L x W x H): 15.28 x 17.13 x 8.15" (388 x 435 x 207 mm) without feet
Shipping size: 23.27 x 23.03 x 17.44" (591 x 501 x 443mm)
Weight: 33.7 lb (15.3 kg)
Shipping Weight: 45.2 lb (20.5 kg)
Operating environment
Temperature: 40 – 95°F (5 – 35°C)
Humidity: 10 – 85% non-condensing
Regulatory approvals
UL/CSA/IEC 60950-1
FCC Class A, CE, CCC, KC, EAC, PSE, CU, SABS, BIS and RCM
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
This product is designed to comply to the rules and regulations required for the product to be sold in various regional markets, including USA/Canada, EU, Norway, Australia/New Zealand, Kuwait, China, Korea, Japan, Mexico, Ukraine, India, Russia, South Africa and Saudi Arabia
RoHS, REACH, WEEE
Limited warranty
3 years parts and labour (including light engine)
Lamp: 500 hours or one year (whichever comes first)
Contact an authorised Christie representative for full details of our limited warranty
