Brightness​
6,600 ISO
6,300 Centre
​5,900 ANSI (typical)
Contrast
3​00,000:1 with Christie RealBlack enabled
250:1 ANSI (nominal)
Display
1DLP 0.65" DMD
Resolution
HD (1920 x 1080)
Illumination
Solid state (laser phosphor)
Lamp Life
20,000 hrs
Inputs
HDMI x 2
3GSDI x 1 (BNC)
DVI-D x 1 (digital only)
VGA (HD15) x 1
USB x 1 (type B mini) - display over USB
USB x 1 (type A) - image viewer or WiFi dongle (optional)
HDBase​T x 1
Ethernet (RJ45) x 1
​Signals
​HDTV formats VGA through to WUXGA (1920 x 1200)​
Pixel clock
162MHz
​Scan rates
​Horizontal: 15kHz to 91kHz
Vertical: 24Hz to 85Hz
​Monitor out
​​3GSDI x 1 (BNC)
Networking
RS-232 in
Control via HDBaseT
Ethernet (10/100) RJ45 with ChristieNET connectivity
Built-in backlit keypad
Wired remote control (3.5mm stereo)
Loop out available for daisy chaining
​Standard accessories
​​IR remote with wired remote jack (wire not included)
AC line cord for projector head
Rear input/keypad panel cover
User manual
Optional accessories
QwikRig Frame
​Christie One Mount Plus (140-117100-XX)
One Mount Extender Rod
One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
Wireless dongle
Lens mount
Tool-free lens insertion system
Boresight adjustable
Motorized horizontal and vertical lens offset
Motorized zoom and focus adjustment
Lens options
​​0.75-0.95:1 Zoom lens (140-119102-XX)
0.95-1.22:1 Zoom lens (140-101103-XX)
1.22-1.52:1 Zoom lens (140-100102-XX)
1.52-2.89:1 Zoom lens (140-102104-XX)
2.90-5.50:1 Zoom lens (140-107109-XX)
​Offsets
​​+/- 120% vertical (+/- 648 px)
+/- 30% horizontal (+/- 288 px)
​Dissipation
​2608.7 BTU/hr ±15% (220V)​
​2693.9 BTU/hr ±15% (110V)​
​Audible noise
35dB(A) standard mode
32dB(A) eco mode
Dimensions
(L x W x H)
Physical: 20.04 x 18.90 x 7.01" (509 x 480 x 178 mm) without feet
Shipping: 30.12 x 23.35 x 14.37"
Weight
Physical: 50.0 lbs (22.6 kg)
Shipping: 59.5 lbs (27.0 kg)
Operating environment
Temperature: 0 to 40°C (32 to 104°F)
Humidity: 0 to 90% non-condensing
​Regulatory
Contact Christie for timing of certifications: UL/CSA/IEC 60950-1
FCC Class A, CE, CCC, KC, EAC, PSE, CU, SABS, BIS, VCCI, RCM, ​UKR, TER, SASO
This product conforms to all relevant European directives, standards, safety, health and environmental concerns RoHS, REACH and WEEE.
Limited warranty
3 years parts and labour on the projector
3 years or 15,000 hours parts and labour​ on the illumination system*
Contact an authorized Christie representative for full details of our limited warrant
