Brightness: 9350 centre lumens, 8500 ANSI lumens
Contrast: 1600-2000:1 Full Field | 650:1 ANSI
Uniformity: 90% brightness uniformity
Display

Type: 3-chip 0.95" DMD
Native resolution: SXGA (1400 x 1050)
Lamp

Type: 1.2kW Cermax® Xenon pre-aligned lamp module
Life:1500 hours typical lamp life

Input

Standard

Analog
Dual link DVI
Optional

Analog
Dual link DVI
SD/HD-SDI
Video Decoder
Twin HDMI
Signals

HDTV formats VGA through to QXGA (2048 x 1536)
Accepts all current HDTV/DTV formats
Multi-standard video decoder
Horizontal and vertical scaling, all inputs
Pixel clock

165MHz
Scan rates

15kHz ‐ 120kHz Horizontal
23.97Hz ‐ 150Hz Vertical
Control and networking
RS232 In/Out
RS422 In
Ethernet (10/100)
USB Device
GPIO (RS232 9 Pin male connector)
Built-in, backlit LCD keypad
Remote control (with optional wired XLR connection)

Lens options

Fixed

ILS Lens 0.73:1 SX+ / 0.67:1 HD*
ILS Lens 1.2:1 SX+ / 1.1:1 HD
Zoom

ILS Lens 1.25–1.6:1 SX+ / 1.16–1.49:1 HD**
ILS Lens 1.5–2.0:1 SX+ / 1.4–1.8:1 HD
ILS Lens 2.0–2.8:1 SX+ / 1.8–2.6:1 HD
ILS Lens 2.8–4.5:1 SX+ / 2.6–4.1:1 HD
ILS Lens 4.5–7.5:1 SX+ / 4.1–6.9:1 HD
ILS Lens 7.5–11.2:1 SX+ / 6.9–10.4:1 HD
Offsets

+/- 100% Vertical
+/- 50% Horizontal
(* +/-23%V +/- 13%H)
(** +/-70%V +/- 45%H)

Accessories

Standard

IR remote
Line cord
Optional

1.2kW Xenon lamp
Analog input card
Dual link DVI input card
Video decoder input card
Dual SD/HD-SDI input card
Twin HDMI input card
DMX512 interface card
ILS lens adapter kit
Portrait display adapter
CT lens mount
Yellow notch filter
Ceiling mount
Ceiling mount extension
Stacking kit
Edge-blending kit
Remote IR sensor
Christie AutoStack™

Enhanced feature sets

Embedded Christie Twist™
Embedded image tiling
Intelligent Lens System (ILS)
Advanced block artifact reduction
ChristieNET™ Web interface
User-friendly, intuitive LCD keypad
Advanced Loop-Thru twin HDMI card
Lamp memory module
User replaceable lamps
Advanced, 10-bit processing
Automatic shut off and ECO mode
Dust-sealed light engine
SNMP (simple network management protocol)
DHCP (dynamic host configuration protocol)
Hybrid stack
Compatibility with legacy accessories

Power requirements

Operating voltage: 200V AC to 240V AC @ 50/60Hz
Max current: 10A @200V
Max power: 2000W
Dissipation: 6830 BTU/hr

Dimensions

Dimensions: (L x W x H): 566 x 660 x 328mm (22.3 x 26.0 x 12.9")
Shipping dimensions: (L x W x H): 851 x 762 x 660mm (33.5 x 30.0 x 26.0")
Weight: 40kg (88lb) (without lens)
Shipping weight: 57kg (125lb)
Operating environment
Temp: 5 – 40°C (40 – 104°F)
Humidity: 20 – 80% noncondensing

Regulatory

Directives (EC) 2002/95/EC (RoHS); 2002/96/EC
(WEEE)
Regulation (EC) No. 1907/2006 (REACH);
CAN/CSA C22.2 No. 60950-1; UL 60950-1; IEC
60950-1; FCC, Part 15, Subpart B, Class A;
EN55022/CISPR22 Class A; EN55024 / CISPR24
Certifications marks:
- cULus (Canada and US)
- CE (EU)
- CCC (China)
- GoST-R (Russia)
- KC (Korea)
- PSE (Japan)
- C-Tick (Australia & New Zealand)
- South Africa
Limited warranty
Three years parts and labour (including light engine)
