Brightness

6,750 (ISO)
6,000 (Center)
6,000 (ANSI)

Color wheel

4 Segment (RGBY) - 2X or 3X speed

Contrast (nominal)

Full On/Off (Christie Real Black Enabled): 4,000,000:1
Dynamic Contrast: 6,000:1
Full On/Off (Christie Real Black Disabled): 1,200:1
ANSI: 250:1

Display

1 x 0.67" DMD

Resolution

1920 x 1200 (2,304,000 pixels) 16:10

Illumination type

High efficiency blue laser phosphor

Illumination lifetime

20,000 hours

Signal inputs

Standard

HDMI x 2
DVI-D x 1 (Digital only)
HD15 x 1
Remote in: 3.5mm stereo female (provides serial communications and power)
HDBaseT (RJ45 x 1)
RJ45 x 1 (Control over wired network connection)

3D

HDMI 1.4, HDBaseT - Frame Packed, Top/Bottom, Side by side
Up to 120Hz output
Does not support frame sequential 3D
3D Sync Out (BNC) - for genlocking projectors or controlling emitters

Signals

HDTV formats VGA through to WUXGA (1920 x 1200)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs

Pixel clock

162MHz

Scan rates

Horizontal: 15 kHz to 91 kHz
Vertical: 24 Hz to 120 Hz

Signal outputs

HDMI x 1

Control & networking

RS232 In
Control via HDBaseT
Ethernet (10/100) RJ45
Built-in backlit keypad
IR remote
Wired remote control (3.5mm stereo)

Accessories

Standard

IR Remote w/ wired remote jack (wire not included)
AC Line cords for projector
User Manual

Optional

Christie One Mount
One Mount Extender Rod
One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
Cable cover GS white

Lens mount

Boresight adjustable
Motorized horizontal and vertical lens offset
Motorized zoom and focus adjustment

Lens options

Lens 0.75-0.95 Zoom G/GS
Lens 0.95-1.22 Zoom G/GS
Lens Zm HP G/GS 1.22-1.52
Lens Zm Std G/599-GS 1.22-1.53
Lens 1.52-2.89 Zoom G/GS
Lens 2.9-5.50:1 Zoom G/GS
Lens UST 0.36 Ultra short throw lens

Power requirements

Operating voltage

Normal: 100-240 VAC @ 50/60 Hz (w/ 15A fuse)

Power consumption

Normal Mode: 650W

Operating current

Normal Mode: 9.5A (100V-240V)

Dissipation

97.5W

Audible Noise (typical 2x Wheel Speed)

34dB(A) Eco2 Mode
36dB(A) Normal Mode

Physical dimensions

(L x W x H)

19.90 x 17.95 x 7.60" without feet or lens
505 x 456 x 190mm without feet or lens

Physical weight

39.94lbs (15.85kg) without lens

Shipping dimensions

(L x W x H)

24.65 x 23.43 x 13.74"
626 x 596 x 349mm

Shipping weight

47.06lb (21.35kg)

Operating environment

0 to 40° C (32 to 104° F), 0-2500 ft altitude
0 to 30° C (32 to 86° F), 5,000-10,000 ft altitude
Humidity: 0 - 85% non-condensing

Regulatory

Contact Christie for timing of certifications: UL/CSA/IEC 60950-1, FCC Class A, CE, FDA, CCC, KC, PSE, CU, SABS, BIS, VCCI, RCM, Ukr, TER, SASO
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, REACH, WEEE

Limited warranty

3 years parts and labor on the projector
3 years or 15,000 hours parts and labor on the illumination system*
Contact an authorized Christie representative for full details of our limited warranty

*Please reference the Christie Standard Limited Warranty document for details.
