Specyfikacja techniczna:

Brightness

6,750 (ISO)
6,000 (Center)
6,000 (ANSI)
Color wheel

4 Segment (RGBY) - 2X or 3X speed
Contrast (nominal)

Full On/Off (Christie Real Black Enabled): 4,000,000:1
Dynamic Contrast: 6,000:1
Full On/Off (Christie Real Black Disabled): 1,200:1
ANSI: 250:1
Display

1 x 0.67" DMD S600HB
Resolution

1920 x 1200 (2,304,000 pixels) 16:10
Illumination type

High Efficiency Blue Laser Phosphor
Illumination lifetime

20,000 hours
Signal inputs

Standard

HDMI x 2
DVI-D x 1 (Digital only)
HD15 x 1
REMOTE IN: 3.5mm stereo female (Provides serial communications and power.)
HDBaseT (RJ45 x 1)
RJ45 x 1 (Control over wired network connection)
3D

HDMI 1.4, HDBaseT - Frame Packed, Top/Bottom, Side By Side
Up to 120Hz output
(Does not support Frame Sequential 3D)
3D Sync Out (BNC) - for genlocking projectors or controlling emitters
Signals

HDTV formats VGA through to WUXGA (1920 x 1200)
Horizontal and vertical scaling while maintaining aspect ratio, all inputs
Pixel clock

162MHz
Scan rates

Horizontal: 15 kHz to 91 kHz
Vertical: 24 Hz to 120 Hz
Signal outputs

HD15 x 1
Control & networking

RS232 In
Control via HDBaseT
Ethernet (10/100) RJ45
Built-in Backlit Keypad
Wired Remote Control (3.5mm stereo)
Accessories

Standard

IR Remote w/ wired remote jack (wire not included)
AC Line cords for projector
User Manual
Optional

Christie One Mount
One Mount Extender Rod
One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
Cable Cover GS White
Lens mount

Boresight adjustable
Motorized horizontal and vertical lens offset
Motorized zoom and focus adjustment
Lens options

Lens 0.75-0.95 Zoom G/GS
Lens 0.95-1.22 Zoom G/GS
Lens Zm Std G/599-GS 1.22-1.53 (Lowest cost for G/555/599/630/635-GS)
Lens Zoom HP G/GS 1.22-1.52 (All G & GS)
Lens 1.52-2.89 Zoom G/GS
Lens 2.9-5.50:1 Zoom G/GS
Lens UST 0.36 (120"), Ultra short throw lens, 630/635/700/850/1075-GS
Lens offsets (max)

+/- 100% Vertical (+/- 600 px)
+/- 30% Horizontal (+/- 288 px)
Power requirements

Operating voltage

Normal: 100-240 VAC @ 50/60 Hz (w/ 15A fuse)
Power consumption

Normal Mode: 650W
Operating current

Normal Mode: 9.5A (100V-240V)
Dissipation

97.5W
Audible Noise (typical 2x Wheel Speed)

34dB(A) Eco2 Mode
36dB(A) Normal Mode
Physical dimensions

(L x W x H)

19.90 x 17.95 x 7.6"
505 x 456 x 190mm w/o feet or lens
Physical weight

34.94 lb (15.85 kg) w/o lens
Shipping dimensions

(L x W x H)

24.65 x 23.43 x 13.74"
626 x 596 x 349mm
Shipping weight

47.06 lb (21.35 kg)
Operating environment

0 to 40° C (32 to 104° F), 0-2500 ft altitude
0 to 30° C (32 to 86° F), 5,000-10,000 ft altitude
Humidity: 0 - 85% non-condensing
Regulatory

Contact Christie for timing of certifications: UL/CSA/IEC 60950-1, FCC Class A, CE, FDA, CCC, KC, PSE, CU, SABS, BIS, VCCI, RCM, Ukr, TER, SASO
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, REACH, WEEE
Limited warranty

3 years parts and labor on the projector
3 years or 15,000 hours parts and labor on the illumination system*
Contact an authorized Christie representative for full details of our limited warranty
*Please reference the Christie Standard Limited Warranty document for details.
