Brightness​
8,400 ISO​​
8,000 Centre​
7,500 ANSI (typical)
Contrast
3​​00,000:1 with Christie RealBlack enabled
250:1 ANSI (nominal)
Display
1DLP 0.67​" DMD
Resolution
WUXGA (1920 x 1200)
Illumination
Solid state (laser phosphor)
Lamp Life
20,000 hrs
Inputs
HDMI x 2
3GSDI x 1 (BNC)
DVI-D x 1 (digital only)​
VGA (HD15) x 1
USB x 1 (type B mini) - display over USB
USB x 1 (type A) - image viewer or WiFi dongle (optional)
HDBase​T x 1
Ethernet (RJ45) x 1
​Signals
​HDTV formats VGA through to WUXGA (1920 x 1200)​
Pixel clock
162MHz
​Scan rates
​Horizontal: 15kHz to 91kHz
Vertical: 24Hz to 85Hz
​Monitor out
​​3GSDI x 1 (BNC)
Networking
RS-232 in
Control via HDBaseT
Ethernet (10/100) RJ45 with ChristieNET connectivity
Built-in backlit keypad
Wired remote control (3.5mm stereo)
Loop out available for display chaining
Optional accessories
QwikRig Frame
Christie One Mount Plus (140-117100-XX)
One Mount Extender Rod
One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
Wireless dongle
Lens mount
Tool-free lens insertion system
Boresight adjustable
Motorized horizontal and vertical lens offset
Motorized zoom and focus adjustment
Lens options
​​0.75-0.95:1 Zoom lens (140-119102-XX)
0.95-1.22:1 Zoom lens (140-101103-XX)
1.22-1.52:1 Zoom lens (140-100102-XX)
1.52-2.89:1 Zoom lens (140-102104-XX)
2.90-5.50:1 Zoom lens (140-107109-XX)
​Offsets
​​+/- 100% vertical (+/- 600 px)
+/- 30% horizontal (+/- 288 px)
Power
Voltage: 110-240V AC @ 50/60Hz
Consumption: 220W max, 110W eco mode
Current: 6.0A max
​Dissipation
​2796.2 BTU/hr ±15% (220V)​​
​​2898.5 BTU/hr ±15% (110V)​​
​Audible noise
35dB(A) standard mode
32dB(A) eco mode
Dimensions
(L x W x H)
Physical: 20.04 x 18.90 x 7.01" (509 x 480 x 178 mm) without feet
Shipping: 30.12 x 23.35 x 14.37"
Weight
Physical: 50.0 lbs (22.6 kg)
Shipping: 59.5 lbs (27.0 kg)
Operating environment
Temperature: 0 to 40°C (32 to 104°F)
Humidity: 0 to 90% non-condensing
​Regulatory
Contact Christie for timing of certifications: UL/CSA/IEC 60950-1
FCC Class A, CE, CCC, KC, EAC, PSE, CU, SABS, BIS, VCCI, RCM,UKR, TER, SASO
This product conforms to all relevant European directives, standards, safety, health and environmental concerns RoHS, REACH and WEEE.
Limited warranty
3 years parts and labor on the projector
3 years or 15,000 hours parts and labor on the illumination system*
Contact an authorized Christie representative for full details of our limited warranty

*Please reference the Christie Standard Limited Warranty document for details
