Brightness

7,900 centre (7,500 ANSI) lumens
Contrast

2500:1 full on, full off
Uniformity

≤90%
Display
Type

1-chip 0.65" DMD
Native resolution

1920 x 1200 WUXGA
Lamp
Type

Dual 350W UHP
Life

Up to 2000 hours in standard mode
Up to 4000 hours in eco mode*
Up to 1000 hours in portrait mode
Input
Standard

Computer D-sub 15 pin mini jack x1
5BNC connector x1
BNC connector x1 (composite)
HDMI connector x2
DVI-D connector x1
RJ-45 x1 (HDBaseT)
D-sub 9 pin x1 (RS232c)
RJ-45 x1 (LAN)
USB type A connector x1 (optional wireless USB or PC-less)
Wired remote control (3.5mm)
5BNC connector x 1
BNC connect x (composite)
Signals

525i(480i)
525p(480p)
625i(576i)
1125i(1080i @ 50/60)
750p(720p @ 50/60)
1125p(1080p @ 50/60)
Pixel clock

27MHz～150MHz
Output
Standard

Computer out D-sub 15 pin mini jack x1
Wired remote control (3.5mm)
Control & networking

RJ-45 x1 (LAN)
RJ-45 x1 (HDBaseT)
D-sub 9 pin x1 (RS232c)
Lenses
Offsets

Vertical: +135 / -50%
(+105 / -50% with extra short throw zoom lens)
Horizontal: +/-22%
Zoom

Extra long throw zoom lens (5.7-9.1)
Extra short throw zoom lens (0.8-1.0)
Short throw zoom lens (1.2-1.8)
Standard zoom lens (1.7-2.6)
Middle throw zoom lens (2.5-3.8)
Long throw zoom lens (3.7-5.9)
Accessories
Standard

Power cord (US cord, 3m) / (Euro cord, 3m)
Power cord (China cord, 3m only for China models)
RGB cable (2m)
Wireless remote control / AA" batteries x2
Adapter cover
Ferrite core and band x2
Cable tie x2
User's Manual
User's Manual CD x1
Safety Guide
Quick Setup Guide
Network Quick Setup Guide
Operating Guide
Network Guide
Instant Stack Guide
Technical Guide
Software License Agreement
Optional

Replacement lamp - P/N 003-005160-01
Replacement hybrid filter - P/N 003-004775-XX
Optional wireless dongle (USB) - P/N 121-116109-XX
Replacement remote
Enhanced feature sets
2 HDMI input
eClarity & HDCR
Built in ultra rich colour wheel
HD Base T
Portrait mode capable
Edge blending
Geometric correction
Status monitor display
Motorised zoom, focus and lens shift with memory
PC-less presentation
Power requirements
(Dual lamp mode)
Operating voltage

110-120V AC
220-240V AC
Current rating

8.8A +10% or less at 110V-120V AC
4.3A+10% or less at 220V-240V AC
Power consumption

AC110 - 120V, 50/60Hz 860W
AC220 - 240V, 50/60Hz 810W
Less than 0.5W @ standby with saving. (AC230V):
Saving mode disables MONITOR OUT, AUDIO OUT, speaker sound, LAN communication and RS232C control except Power ON command in standby
Thermal dissipation

3618BTU(110-120V)
3379BTU(220-240V)
Dimensions
Dimensions (LxWxH) (without lens and feet in min. position)

(LxWxH) 463mm x 537mm x 174mm
(LxWxH) 18.2" x 21.1" x 6.9"
Net weight (without lens)

17.0kg max (37.5 lbs)
Shipping dimensions

(LxWxH) 561mm x 743mm x 315mm
(LxWxH) 22.1" x 29.3" x 12.4"
Shipping weight

22.5kg (49.6lbs)
Operating environment
Noise

Standard mode: 36dBA / 29dBA Eco mode
Temperature

32-113°F (0-45°C) from sea level to 1600m (5249 feet)
32-104°F (0-40°C) from 1600m (5249 feet) to 3048m (10000 feet)
Altitude

0 to 10000 feet (0 to 3048m)
Humidity

10-80% non-condensing
Regulatory
This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC)

FCC, Part 15, Subpart B, Class A
EN55022/CISPR22 Class A
ICES/NMB003 (A)
EN55024 / CISPR24
IEC 60950-1
UL 60950-1
EN 60950-1
CAN/CSA C22.2 No. 60950-1
Directive 2011/65/EU (RoHS)
Directive 2012/19/EU (WEEE)
EU Regulation (EC) No. 1907/2006 (REACH)
Certifications marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), EAC (Russia), RCM (Australia and New Zealand), India (BIS), Mexico (NOM), Saudi Arabia, South Africa
Limited warranty
3 years parts and labour (including light engine)
Lamp: 500 hours or one year (whichever comes first)
Contact an authorised Christie representative for full details of our limited warranty
