15,000 ANSI lumens
3000:1 contrast ratio
>90% brightness uniformity
Display
3 x 1.64" Inorganic LCD panels
Native 2K (2048 x 1080) resolution
Lamp
4 x 380W Ushio NSHA
Normal mode 2000 hours, eco mode 3000 hours
Signal Compatibility
VGA through 2K (2048 x 1080)
Video Signal
Accepts current HDTV/DTV formats (480i, 480P, 720P, 1080i, 1080p, 1080psf)
Pixel Clock
230MHz ~ 162MHz
Inputs, Control and Networking
DVI-D x 1 (HDCP Compliant)
HDMI x 1
D-Sub 15 x 1
BNC x 5 (R,G,B,H,V & Y, Pb/Cb, Pr/Cr & Composite)
Mini DIN 4-pin (S-video)
RJ-45 LAN x 1
Dsub-9 x 1
2 x option input card slots
Control port Dsub-9 x 1
R/C Jack – Mini jack x 1
Optical System
Power adjustable zoom, focus and lens shift
Motorized light shutter
Standard Accessories
Quick set-up manual
Real color management software instruction
Lens spacer for optional lenses
Light block sheet
Mounting clamp
Lens cover strap
Power cord
AC cord UL type (NEMA 6-20P plug type)
Computer cable (Dsub15-Dsub15)
Remote control
Optional Accessories
DVI/Dsub15 input card
5 BNC/S-video input card
SDI-Dual input card (HD-SDI only)
Dual Link input card*
380W Ushio NSHA lamps
Smoke filter kit
Disposable smoke filter
Robotic AutoFilter cartridge
*Required for full 2048 x 1080 resolution

Enhanced Feature Sets
4D Color™ technology
*Stackable design for added brightness
Auto-switching lamp feature (single lamp mode)
Digital keystone feature (Max: V±30°, H±30°)
Robotic AutoFilter cartridge (up to 12,000 hours) maintenance free operation
Built-in RS 232c port
Customizable start-up logo
Selectable aspect ratio 4:3,16:9, 17:9
Top loading lamps
Intuitive graphical user interface
Built-in keypad (power on/standby, menu, up, down, left, right arrows)
Front and rear infrared sensors for IR keypad
Carrying handles
Auto discoloration prevention with 3D-AUCC technology
Top access to LCD panels- simplifies cleaning
Optional smoke filter kit
Optional input slots for additional connectivity
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application

Power Requirements
Operating voltage: 200-240V ±10%
Operating current: 11.0A max 200V
Operating power: 1850W (200-240V)
Dissipation: 7,100 BTU/hr
Dimensions
Body size (LxWxH): 32.1 x 25.6 x 13.7" (815 x 650 x 349mm)
Weight: 102.5lbs (46.5kg) without lens
Shipping size (LxWxH): 39.7 x 34.1 x 22.0" (1008 x 865 x 560mm)
Shipping weight: 125.7lbs (57.0kg)
Noise
51dBA standard mode
48dBA eco mode
Operating Environment
Operating temperature: 41-104˚F (5-40˚C)
Humidity (non-condensing): 20-80%
Altitude: 0-8858ft (0-2700m)
Regulatory Approvals
This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):
FCC, Part 15, Subpart B, Class A
EN55022/CISPR22: Class A
EN55024/CISPR24
IEC 60950-1
UL 60950-1
CAN/CSA C22.2 No. 60950-1
Directive (EC) 2002/95/EC (RoHS)
Directive 2002/96/EC (WEEE)
Regulation (EC) No. 1907/2006 (REACH)
Limited Warranty
Projector: 3 years parts and labor
Lamp: 500 hours or one year (whichever comes first) or Contact an authorized Christie representative for full details of our limited warranty

Due to constant research, specifications and features are subject to change without notice.
