7000 ANSI lumens
Contrast Ratio: 3000:1 (full on/off)
90% Brightness Uniformity (corner to corner)
Display
3 x 1.2" Inorganic LCD
Full HD 1920 x 1080
Lamp
380W Ushio NSHA x1
Normal Mode: 2000 hours
Eco Mode: 3000 hours
Input Signal Compatibility
UXGA/SXGA+/SXGA/WXGA/XGA/SVGA/VGA, MAC, NTCS, PAL, SECAM, NTSC4.43, PAL-M, PAL-N . Video (480i, 480P, 720P, 1080i, 1080p, 1080psf )
Pixel Clock
162 MHz. Analog ; 162 MHz Digital
Scan Rates
Horizontal: 15kHz to 120kHz
Vertical: 38Hz to 120Hz
Inputs, Control and Networking
Input #1: DVI-D x 1 (HDCP Compatible ), HDMI (V1.3 with DeepColor Compatible)
Input #2: BNC x 5 (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite), D-sub 15 x 1
Input #3: S-Video -DIN 4-pin x 1 ; RCA x3 (Video/Y, Pb/Cb,Pr/Cr)
Control: Serial Input – Dsub-9x1; CCM-LX input connector
Network: RJ-45 x1 (LAN)
Serial Output: Dsub-9 x 1. R/C jack: mini jack x 1
Optical System
Motorized zoom, focus and lens shift
Mechanical light shutter
Lenses
Fixed

Short 0.8:1
Zoom

Short 1.3-1.8:1
Standard 1.8-2.3:1
Semi long 2.3-4.2:1
Long Zoom 4.3-6.0:1
Ultra Long 5.7-9.0:1
Digital Keystone

V +/- 40°, H +/- 20° and 3D Keystone™
Accessories
Standard

Quick setup manual
Real Color Management software instruction
Lens spacer for option lenses
Light-block sheet
Mounting clamp
Lens cover strap
Power cord
AC cord UL type (NEMA 6-20P plug type) 3 meters
AC cord European2P plug type 3 meters
Computer cable (Dsub15-Dsub15)
Remote control
Optional

CCM-LX Network Module
380W USHIO NSHA lamp
AutoFilter cartridge
Enhanced Feature Sets
4DColor™ technology
Crestron RoomView™
AMX Device Discovery
Edge blending and color matching
360 degree on-axis rotation
PiP and PbyP
*Stackable design for redundancy or added brightness
Digital keystone
AutoFilter cartridge (up to 10,000 hours) maintenance free operation
Customizable start-up logo
Native 16:9; selectable aspect ratio 4:3 and true mode
Intuitive graphical user interface
Built-in keypad (power on/standby, menu, up, down, left, right arrows)
Front and rear infrared sensors for IR keypad
Auto discoloration prevention with 3D-AUCC technology
Top access to LCD panels- simplifies cleaning and maintenance
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application

Power Requirements
Operating voltage: 100-120 V AC +/- 10% / 200-240 V AC +/- 10%
Operating current: 6.0 A
Power: 520 W (Lamp Normal 100-120V), 500 W (Lamp Normal 200-240V)
Dissipation: 2020 BTU/h
Dimensions
Body size (LxWxH): 17 x 14.5 x 7.36" (439.9 x 370.0 x 187.0mm) - body only, without lens; feet at minimum height position
Shipping size (LxWxH): 24.8 x 19.3 x 15.2" (630x 492x 388mm)
Weight: 25.1lb (11.4kg) (without lens)
Shipping Weight: 35.1lb (15.9kg) without Lens
Operating Environment
Temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: 14˚F to 140˚F (-10˚C to 60˚C)
Humidity: 20% to 80% non-condensing
Operating Noise
Normal mode: 42 dBA
Eco Mode: 38 dBA
Regulatory Approvals
Directives (EC) 2002/95/EC (RoHS); 2002/96/EC (WEEE)

Regulation (EC) No. 1907/2006 (REACH); CAN/CSA C22.2 No. 60950-1; UL 60950-1; IEC 60950-1; FCC, Part 15, Subpart B, Class A; EN55022/CISPR22 Class A; EN55024 / CISPR24

Certifications marks:
- cULus (Canada and US)
- CE (EU)
- CCC (China)
- GoST-R (Russia)

Limited Warranty
Projector: 3 years parts and labor
Lamp: 500 hours or one year (whichever comes first)
Contact an authorized Christie representative for full details of our limited warranty

Due to constant research, specifications and features are subject to change without notice.
