4000 ANSI lumens
2000:1 (Full on/off)
Display Technology
3 x 0.59" inorganic LCD
WXGA 1280 x 800 resolution
245W UHP lamp
Signals Compatibility
SDTV: 480i, 480p, 576i,576p • HDTV: 720p @ 50/60Hz, 1080i @ 50/60Hz, 1080p @ 50/60Hz
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA, MAC 16"
Scan Rates
27-162 MHz (see user's manual for detail information)
Inputs, Controls and Networking
Video Input: S-video – Mini Din 4 pin x 1; Composite video – RCA x 1; Component video – RCA x 3
Audio Input: 3.5 mini x 2 RCA x 2 (L/R)
Computer Input: D-sub 15 pin x 1
HDMI Input: HDMI x 1 (HDCP compliant)
USB: USB type A x1 for PC-Less presentation; USB type B x 1 for USB display or mouse control
LAN: RJ45 x 1 wired network
Microphone input: Mono 3.5 mini x 1 (Dynamic and unbalanced microphone)
Optical system
Standard lens included – 1.7 x zoom lens
Manual zoom and focus (1.5-2.5:1 throw ratio)
Vertical lens shift Up/Down ± 60%
Horizontal lens shift left/right ± 10% (calculations based on center lens center image using standard zoom lens)
Standard lens
1.5-2.5:1 throw ratio, zoom and focus
Digital keystone
Automatic and manual keystone
Horizontal: ±30 degrees • Vertical: ±30 degrees*

*3D digital keystone (geometry correction).

Standard accessories
Computer cable
Remote control
Lens cover
Power cord
User manual
Security label
Optional accessories
Lamp (003-120730-XX)
Hybrid filter (003-004239-XX)
Enhanced feature sets
AMX Device Discovery; blackboard/whiteboard mode
Daytime mode
3D Keystone geometry correction
Closed caption (NTSC and component 480i only)
Stackable*
Text message capabilities via network
16W mono speakers
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application.

Power requirements
operating voltage: 100-120 VAC ±10%
200-240 VAC ±10%
operating current: 50A @ 100-120V
100A @ 220-240V
consumption: 380W AC100-120V @ 50/60Hz • 360W AC220-240V @ 50/60Hz
dissipation: 1292 BTU/hr @ 100-120V • 1224 BTU/hr @ 220-240V
Dimensions (LxWxH)
(LxWxH): 12.5 x 15.8 x 4.6" (318 x 401 x 118mm)
shipping size • (LxWxH): 16.5 x 22.0 x 7.8" (420 x 560 x 197mm)
weight • 10.6lbs (4.8kg)
shipping weight • 18.1lbs (8.2kg)
Operating environment
Standard mode: 36dBA
Eco mode: 30dBA
Temperature: 41-95°F (5-35°C)
Humidity (non condensing): Operating 10-85%, Storage 10-85%
Regulatory Approvals
This product conforms to the following regulations related to product safety, environmental requirements
and electromagnetic compatibility (EMC) • FCC, Part 15, Subpart B, Class A • EN55022/CISPR22 Class A • EN55024/CISPR24
• IEC 60950-1 • UL 60950-1 • CAN/CSA C22.2 No. 60950-1• Directive (EC) 2002/95/EC (RoHS) • Directive 2002/96/EC (WEEE)
• EU Regulation (EC) No. 1907/2006 (REACH)
• Certifications marks (check with Christie for latest update): cULus (Canada and the US), CE (EU), CCC (China), GoST-R (Russia),
C-Tick (Australia and New Zealand), South Africa
Limited Warranty
Projector: three years parts and labor
Lamp: 500 hours or one year (whichever comes first)
Contact an authorized Christie representative for full details of our limited warranty
