Brightness: 5,500 ANSI lumens
Contrast: Up to 3000:1

Display technology and resolution

3 x 0.76" inorganic LCD
1280 x 800 native WXGA

Lamp

330W UHP lamp
Standard mode: 2,500 hours; eco mode: 3,000 hours

Input signal compatibility

UXGA/SXGA+/SXGA/WXGA/XGA/WXGA/SVGA/ VGA, MAC16", NTCS, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, 480I, 480P, 576I, 720P, 1080i 1080p

Scan rates

Horizontal: 15-106kHz
Vertical: 56-120Hz

Pixel clock

27MHz ~ 162MHz

Inputs, control and networking

Input 1: D-Sub 15 x 1 (Component support)
Input 2: 5-BNC (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite)
Digital inputs: HDMI x 2, S-video DIN 4-pin x 1, Composite video RCA x 1
Component video RCA x 3, USB input type A x 2 for optional wireless network), USB type B x 1 (for USB display or mouse control), Audio In - Mini jack x 2 (3.5 mm stereo), RCA jack (L,R) x 1
Output RCA (L & R) x 1, Network (LAN) RJ-45 x 1 (wired LAN), Control terminals 9-pin D-sub x 1 for RS-232C (serial)
Control 9-pin D-sub x 1 for RS-232C (serial)

Optical system

Motorized zoom, focus and lens shift
Mechanical light shutter

Fixed lens

0.8:1

Zoom lenses

Short zoom 1.2-1.8
Medium zoom 1.5-3.0*
Long zoom 2.8-4.9
Ultra long zoom 4.9-8.3

*Lens ships standard
Digital keystone

Horizontal: ± 20 degrees
Vertical: ± 12 degrees
8-point geometry correction

Standard accessories

Power cord (US cord, 1.8m) x 1
(UK cord, 1.8m) x 1
(Euro code, 1.8m) x 1
Computer cable (2m) x 1
HDMI-DVI cable (0.4m) x 1
Wireless remote control x 1 & "AA" Batteries x 2
Security label x 1
Lens cover x 1
Adapter cover x 1
Cable holder x 1
Network and wireless software (in a CD-ROM)
User's manual CD

Optional accessories

Wireless adapter
Hybrid filter
330W UHP lamp

Enhanced feature sets

Crestron RoomView™
AMX Device Discovery
360-degree on axis rotation
Picture-by-picture
Dual-stack control
Digital keystone feature
Hybrid filter up to 20,000 hours maintenance-free
Customizable start-up logo
Selectable aspect ratio 16:9 and true mode
Intuitive graphical user interface
Graphical on-screen lens range
LCD menu for easy set up and maintainence
Front and rear infrared sensors for IR keypad
Supports simple curved screens
Stackable*design for redundancy or added brightness
Built-in security features and menu settings
Repeatable lens recall capabilities**
16W stereo speakers

*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application.

**Not available on fixed lenses and does not include zoom or focus capabilities.
Power requirements

Operating voltage: AC100 -120V, 50/60Hz • AC220 -240V, 50/60Hz
Operating current: 4.9A max at 100V AC • 2.4A max at 220V AC
Consumption: • 480W AC100 -120V • 455W AC220 -240V
Dissipation: 1683 BTU/hr @ 100-120V • 1553 BTU/hr @ 220-240V

Dimensions (LxWxH)

Body: (LxWxH): 18.7 x 19.6 x 5.8" (476 x 498 x 147mm) (with standard lens)
Shipping size: (LxWxH): 26.9 x 21.7 x 9.0" (683 x 552 x 229mm)
Weight: 19.6lbs (8.9kg) (with standard lens)
Shipping weight: 28.0lbs (12.7kg)

Operating environment

Noise: Standard mode: 35 dBA / 29 dB Eco mode
Temperature: 32-104°F (0-40°C)
Humidity: 10-85% non-condensing

Regulatory approvals

This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC)
FCC, Part 15, Subpart B, Class
EN55022/CISPR22 Class A
EN55024 / CISPR24
IEC 60950-1
UL 60950-1
CAN/CSA C22.2 No. 60950-1
Directive (EC) 2002/95/EC (RoHS)
Directive 2002/96/EC (WEEE)
EU Regulation (EC) No. 1907/2006 (REACH)
Certifications marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), C-Tick (Australia and New Zealand), South Africa

Limited warranty

Projector: three years parts and labour
Lamp: 500 hours or one year (whichever comes first)
Contact an authorised Christie representative for full details of our limited warranty
