4200 ANSI lumens
1000:1 contrast ratio
>90% brightness uniformity
Display
3 x 0.76" Inorganic LCDs
Native WUXGA 1920 x 1200 resolution
Lamp
275W UHB
Normal mode 2000 hours, eco mode 3000 hours
Signal Compatibility
VGA through WUXGA (1920 x 1200)
Video Signal
Accepts current HDTV/DTV formats (480i, 480p, 576i, 720p, 1080i, 1080p)
NTSC, NTSC 4.43, PAL, PAL M, SECAM, PAL-N
Pixel Clock
27MHz ~ 150MHz
Inputs, Control and Networking
HDMI v1.3 x 1 (HDCP Compliant)
HD 15 x 1
BNC x 5 (R,G,B,H,V & Y, Pb/Cb, Pr/Cr & Composite)
YPbPr (component video RCA x 3), 1 RCA composite video
Mini DIN 4-pin (S-video)
Audio input (x 4), Dsub-9 x 1
LAN port
R/C Jack – Mini jack x 1
Output HD 15 x 1 (loop-through)
Audio output x 1 mini jack
Output: 8W Stereo
Optical System
Manual zoom, focus and lens shift
Ships with a standard 2x zoom lens 1.5-2.9:1
Standard Accessories
RGB cable
Users manual
Wireless remote control unit
Security label
Power cord (US, UK, Euro)
Ships with standard lens: 1.5-2.9:1 Zoom Lens
Optional Accessories
Filter cartridge
Replacement lamp (including filter cartridge)
Enhanced Feature Sets
Aspect Ratio Selection; Native 16:10, 16:9, 4:3, Auto Detect
Dynamic iris control
Customizable start-up logo
Auto Digital keystone H/V
Anti-theft: kensington style slot and security bar
Support for closed caption video display (NTSC)
RJ45 LAN connection with network control and SNMP monitoring
3D Keystone™ advanced four corner geometry correction
Picture-by-Picture (PbyP)
Power Requirements
Operating voltage: 100-120 VAC ±10%/200-240 VAC ±10%
Operating current: 5.0A max @ 100-120 VAC 50/60Hz; 2.1A max @ 200-240 VAC 50/60Hz
Operating power: 460W max
Dissipation: 1569 BTU/hr
Dimensions
Body size with lens (LxWxH): 14.1 x 16.5 x 5.5" (357 x 418 x 139mm)
Weight: 15.9lbs (7.2kg) with lens
Shipping size (LxWxH): 18.8 x 21.6 x 9.6" (478 x 555 x 244mm)
Shipping weight: 26.4lbs (12kg)
Noise
36dBA standard mode
30dBA eco mode
Operating Environment
Operating temperature: 41-95˚F (5-35˚C)
Storage temperature: -4-140˚F (-20-60˚C)
Humidity (non-condensing): 10-85%
Altitude: 0 to 75000 feet / 0 to 2286 m
Regulatory Approvals
This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC):
FCC Part 15, Subpart B Class A
CISPR22/EN55022
CISPR24/EN55024
UL 60950-1 first edition
CAN/CSA-C22.2 No 60950-1-03 first edition
IEC60950-1:2001
2002/95/EC RoHS
Limited Warranty
Projector: 3 years parts and labor
Lamp: 500 hrs or 120 days (whichever comes first) or Contact an authorized Christie representative for full details of our limited warranty

Due to constant research, specifications and features are subject to change without notice.
