4200 ANSI lumens
3000:1 contrast ratio
Display
3 x 0.76" Inorganic LCDs
WUXGA 1920 x 1200 resolution
Lamp
245W UHP lamp
Input signal compatibility
UXGA/SXGA+/SXGA/WXGA/XGA/WXGA/SVGA/ VGA, MAC16", NTCS, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, 480I, 480P, 576I, 720P, 1080i 1080p
Scan rates
Horizontal: 15-106kHz • Vertical: 56-120Hz
Pixel Clock
27MHz ~ 162MHz
Inputs, Control and Networking
Input 1: D-Sub 15 x 1 (Component support)
Input 2: 5-BNC (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite)
Digital inputs: HDMI x 2, S-video DIN 4-pin x 1, Composite video RCA x 1
Component video RCA x 3, USB input type A x 2 for optional wireless network), USB type B x 1 (for USB display or mouse control), Audio In - Mini jack x 2 (3.5 mm stereo), RCA jack (L,R) x 1
Output RCA (L & R) x 1, Network (LAN) RJ-45 x 1 (wired LAN), Control terminals 9 pin D-sub x 1 for RS-232C (serial)
Control
9 pin D-sub x 1 for RS-232C (serial)
Optical System
Motorized zoom, focus and lens shift •Mechanical light shutter
Fixed lens
0.8:1
Zoom lenses
Short zoom 1.2-1.8 • Medium zoom 1.5-3.0*
Long zoom 2.8-4.9
Ultra-long zoom 4.9-8.3
*Lens ships standard

Digital keystone
Horizontal: ± 20 degrees
Vertical: ± 12 degrees
8-point geometry correction
Standard Accessories
Power cord (US cord, 1.8m) x 1, (UK cord, 1.8m) x 1 and (Euro code, 1.8m)x 1 Computer cable (2m) x 1
HDMI-DVI cable (0.4m) x 1
Wireless remote control unit x 1 and "A" batteries x 2
Security label x 1
Lens cover x 1
Adapter cover x 1
Cable holder x 1
Network and wireless software (in a CD-ROM)
User's manual CD
Optional Accessories
Wireless adapter
Hybrid filter
245W UHP lamp
Enhanced Feature Sets
Crestron RoomView
AMX Device Discovery
360-degree on axis rotation
Picture-in-picture
Picture-by-Picture
Dual-stack control
Digital keystone feature
Hybrid filter up to 20,000 hours maintenance-free
Customizable start-up logo
Selectable aspect ratio 16:9 and true mode
Intuitive graphical user interface
Graphical on-screen lens range
Built-in keypad (power on/standby, menu, up, down, left, right arrows)
Front and rear infrared sensors for IR keypad
Supports simple curved screens
Stackable*design for redundancy or added brightness
Built-in security features and menu settings
Repeatable lens recall capabilities**
16W stereo speakers
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application.

**Not available on fixed lenses and does not include zoom or focus capabilities.

Power Requirements
Operating voltage:

375W AC100-120V @ 50/60Hz
355W AC220-240V @ 50/60Hz
3.8A max @ 100V AC
1.9A max @ 220V AC
Operating current:

50A @ 100-120V
100A @ 220-240V
Consumption:

375W AC100-120V, 50/60Hz
355W AC220-240V, 50/60Hz
*<.035W@ AC230V(50/60hz) in standby with saving mode
Dissipation:

1280 BTU/hr @ 100-120V
1212 BTU/hr @ 220-240V
Dimensions
Body: (LxWxH): 18.7 x 19.6 x 5.8" (476 x 498 x 147mm) (with standard lens)
Shipping size: (LxWxH): 26.9 x 21.7 x 9.0" (683 x 552 x 229mm)
Weight: 18.7 lbs (8.5kg) (with standard lens)
Shipping weight: 27.1lbs (12.3kg)
Operating Environment
Noise: Standard mode: 35 dBA / 29 dB Eco mode
Temperature: 32-104°F (0-40°C)
Humidity: 10-85% noncondensing
Regulatory Approvals
This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic
compatibility (EMC) • FCC, Part 15, Subpart B, Class A • EN55022/CISPR22 Class A • EN55024 / CISPR24 • IEC 60950-1
• UL 60950-1 • CAN/CSA C22.2 No. 60950-1 • Directive (EC) 2002/95/EC (RoHS) • Directive 2002/96/EC (WEEE)
• EU Regulation (EC) No. 1907/2006 (REACH)
• Certifications marks (check with Christie for latest update): cULus (Canada and the US), CE (EU), CCC (China), GoST-R (Russia),
C-Tick (Australia and New Zealand), South Africa
Limited Warranty
Projector: three years parts and labor
Lamp: 120 days or 500 hours (whichever comes first)
Contact an authorized Christie representative for full details of our limited warranty
