12,000 lumens
Contrast Ratio: 4000:1 (full on/off)
90% Brightness Uniformity (corner to corner)
Display Technology
3 x 1.8" Inorganic LCD
Native XGA 1024x768
Lamp
Dual 330W Ushio NSHA
Normal Mode: 2000 hours
Eco Mode: 3000 hours
Input Signal Compatibility
UXGA/SXGA+/SXGA/WXGA(Compression)/XGA/SVGA/VGA, MAC, NTCS, PAL, SECAM, NTSC4.43, PAL-M, PAL-N . Video (480i, 480P, 720P, 1080i)
Pixel Clock
Analog 230MHz / Digital 162MHz
Scan Rates
Horizontal: 15kHz to 120kHz
Vertical: 48Hz to 120Hz
Inputs, Control and Networking
Input #1: DVI-D x 1 (Compatible with HDCP), D-Sub15 x 1
Input #2: BNC x 5 (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite), Mini DIN 4-pin (S-video)
Input #3: Option card slot
Input #4: Option card slot
Control: Serial Input – Dsub-9 x 1
Serial Output: Dsub-9 x 1. R/C jack: mini jack x 1
Optical System
Motorized zoom, focus and lens shift
Mechanical light Shutter
Lenses
Fixed

Short 0.8:1
Short 1.2:1
Zoom

Short 1.4-1.8:1
Short 1.5-2.0:1
Short 1.2-1.5:1
Standard 2.0-2.6:1
Standard 2.6-3.5:1
Semi long 3.5-4.5:1
Long Zoom 4.4-6.2:1
Long 6.3-9.0:1
Digital Keystone

V +/- 40°, H +/- 20°
Accessories
Standard

Quick setup manual
Real Color Management software instruction
Lens spacer for optional lenses
Light-block sheet
Mounting clamp
Lens cover strap
Power cord
AC cord UL type (NEMA 6-20P plug type) 3 meters
AC cord European2P plug type 3 meters
Computer cable (Dsub15-Dsub15)
Remote control
Optional

DVI/Dsub15 input card
5 BNC/S-video input card
SDI-Dual input card (HD-SDI only)
CCM-LX-i- Network Input Card
AutoFilter cartridge
Enhanced Feature Sets
4DColor™ technology
Illuminated control panel
*Stackable design for redundancy or added brightness up to 24,000 lumens
Auto-switching lamp (single lamp mode)
Digital keystone
AutoFilter cartridge (up to 10,000 hours) maintenance free operation
Built-in RS 232c port
Customizable start-up logo
Native 4:3; selectable aspect ratio 16:9 and true mode
Top loading lamps
Intuitive graphical user interface
Built-in keypad (power on/standby, menu, up, down, left, right arrows)
Front and rear infrared sensors for IR keypad
Carrying handles
Auto discoloration prevention with 3D-AUCC technology
Top access to LCD panels - simplifies cleaning and maintenance
360 degree on-axis rotation
*In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application

Power Requirements
Operating voltage: 100-120 V AC +/- 10% / 200-240 V AC +/- 10%
Operating current: 4.8A max at 200V(9.9A max at 100V)
Power: 940W typ.(3207[BTU/h]) (Normal 100V/9.9A)
895W typ. (3054[BTU/h]) (Normal 220V/4.8A)
940W typ.(3207[BTU/h]) (Normal 100V/9.9A)
895W typ. (3054[BTU/h]) (Normal 220V/4.8A)
Dissipation: 3207BTU/hr
Dimensions
Body size: (L x W x H) 29.8 x 20.9 x 10.5" (757.0 x 530.0 x 267.5mm) (body only, without lens; feet at minimum height position)
Shipping dimensions: 37.4 x 33.3 x 21.3" (951.0 x 846.0 x 542.0mm)
Weight: 60.9 lbs (27.6 kg) (without lens)
Shipping weight: 83.8 lbs (38.0 kg)
Operating Environment
Temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: 14˚F to 140˚F (-10˚C to 60˚C)
Humidity: 20% to 80% non-condensing 0 to 8858ft (0 to 2700 m)
Noise: Normal mode: 42 dBA, Eco mode: 39 dBA
Regulatory Approvals
Directives (EC) 2002/95/EC (RoHS); 2002/96/EC (WEEE)
Regulation (EC) No. 1907/2006 (REACH)
· CAN/CSA C22.2 No. 60950-1
· UL 60950-1,
· IEC 60950-1,
· FCC, Part 15, Subpart B, Class A
· EN55022/CISPR22 Class A
· EN55024 / CISPR24
Certifications marks
· cULus (Canada & US)
· CE (EU)
· CCC (China)
· GoST-R (Russia)

Limited Warranty
Projector: 3 years parts and labor
Lamp: 500 hours or one year (whichever comes first)
Contact an authorized Christie representative for fulldetails of our limited warranty

Due to constant research, specifications and features are subject to change without notice
