Brightness
16,000 ANSI lumens
17,500 center lumens
Contrast
2500:1 (full on/off)
Uniformity
90% brightness uniformity (corner to corner)
Display
3 x 1.8" Inorganic LCDs, with 4DColor™ technology (yellow LCD color device)
Resolution
Native XGA (1024 x 768) 4:3
Illumination
4 x 380W Ushio NSHA
Lamp Life
Normal mode: up to 2000 hrs
Eco mode: up to 3000 hrs
Inputs
HDMI x 1, DVI-D x 1, D-Sub15 x 1
BNC x 5 (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite), Mini DIN 4-pin (s-video)
Serial input: RS-232 x 1
RJ45 LAN x 1
USB x 1 (type B) - service only
Signals
Accepts and displays all currently known HDTV formats (480i, 480P, 720P, 1080i, 1080p, 1080psf) via RGB connection. WUXGA/UXGA/SXGA+/SXGA/WXGA/XGA/SVGA/VGA
Pixel clock
Analog 230 MHz
Digital 162 MHz
Scan rates
Horizontal 15 - 120 kHz / 26 - 80 kHz (HDMI / DVI-D)
Vertical: 48 - 120 Hz / 23 - 85 Hz (HDMI / DVI-D)
Outputs
Serial output: RS-232 x 1
R/C jack x 1
RJ45 LAN x 1
Lenses
Fixed
Short 0.8:1 (103-135100-XX)
Zoom
Short 1.2-1.5:1 (103-103101-XX)
Short 1.4-1.8:1 (38-809037-XX)
Short 1.5-2.0:1 (38-809094-XX)
Standard 2.0-2.6:1 (38-809039-XX)
Standard 2.0-2.6:1 (103-138103-XX) compatible L2K1000/L2k1500 lens
Standard 2.6-3.5:1 (38-809044-XX)
Semi long 3.5-4.5:1 (103-129103-XX)
Semi long 3.5-4.5:1 (103-139104-XX) compatible L2K1000/L2k1500 lens
Long Zoom 4.4-6.2:1 (103-130105-XX) Long 6.3-9.0:1 (38-809070-XX)
Digital keystone
Verical: +/- 40˚
Horizontal: +/- 40˚
Standard Accessories
Quick setup manual
Real Color Management software instruction
Lens spacer for option lenses
Light-block sheet
Mounting clamp
Lens cover strap
Power cord
AC cord UL type (NEMA 6-20P plug type) 3 meters
AC cord European2P plug type 3 meters
Computer cable (Dsub15-Dsub15)
Remote control
Optional accessories
DVI/Dsub15 input card(103-134109-XX)
5 BNC/S-video input card (103-133108-XX)
SDI-Dual input card (HD-SDI only) (103-132107-XX)
380W USHIO NSHA lamps (003-120599-XX)
Smoke filter kit (003-004739-XX)
Disposable smoke filter material (003-003705-XX)
Enhanced feature sets
Stackable design for added brightness
Auto-switching lamp feature (dual or quad lamp modes)
Digital keystone feature (Max: V±30°, H±30°)
Built-in RS 232c port
Customizable start-up logo
Selectable aspect ratio 4:3,16:9, 17:9
Top loading lamps
Intuitive graphical user interface
Built-in keypad (power on/standby, menu, up, down, left, right arrows)
Front and rear infrared sensors for IR keypad
Carrying handles
AMX Device Discovery
Top maintenance access to LCD panels- simplifies cleaning
Optional smoke filter kit
Optional input slots for additional connectivity
LED illumination control panel
Power
voltage: 200-240VAC @ 50/60 Hz
consumption: 1850W
current: 11.0A max at 200V
Dissipation
6986 BTU/hr
Audible noise
Standard Mode: 51dB(A), Eco Mode: 48dB(A)
Dimensions
(L x W x H)
physical: 32.1 x 25.6 x 13.7" (815 x 650 x 349 mm) without lens, feet at minimum height
shipping: 39.7 x 34.1 x 21.5" (1008 x 865 x 545 mm)
Weight
physical: 102.5 lbs (46.5 kg) (without lens)
shipping: 125.7 lbs (57.0 kg) (without lens)
Operating environment
5 to 40°C (40 to 104°F) (sea level to 1,800m)
5 to 30°C (40 to 86°F) (1,800~2,700m sea level)
Storage temperature: -10 to 60°C (14 to 140°F)
Altitude: 0-8858ft (0-2700m)
Humidity: 20 to 80% non-condensing
Regulatory
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
Directives: RoHS, REACH, WEEE
Regulations: UL/CSA/IEC 60950-1
FCC Class A
CE
CCC
EAC
SABS
RCM
This product is designed to comply to the rules and regulations required for the product to be sold in various regional markets, including USA/Canada, EU, Australia/New Zealand, China, Mexico, Russia, South Africa, India (pending) and Saudi Arabia
Limited warranty
Projector: 3 years parts and labor
Lamp: 1 year or 500 hour total operation whichever occurs first
Contact an authorized Christie representative for full details of our limited warranty
