Brightness: 5,000 ANSI lumens
Contrast: Up to 3000:1
Display technology and resolution
3 x 0.63" inorganic LCD
1024 x 768 native XGA
Lamp
245W UHP lamp
Normal mode 2500 hours, eco mode up to 4000 hours
Input signal compatibility
UXGA/SXGA+/SXGA/WXGA/XGA/WXGA/SVGA/ VGA, MAC16", NTCS, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, 480I, 480P, 576I, 720P, 1080i 1080p
Scan rates
Horizontal: 15-106kHz
Vertical: 56-120Hz
Pixel clock
162 MHz (digital and analog)
Inputs, control and networking
Input 1: D-Sub 15 x 1 (Component support)
Input 2: 5-BNC (R, G, B, H, V & Y, Pb/Cb, Pr/Cr & Composite)
Digital inputs: HDMI x 2, S-video DIN 4-pin x 1, Composite video RCA x 1
Component video RCA x 3, USB input type A x 2 for optional wireless network), USB type B x 1 (for USB display or mouse control), Audio In - Mini jack x 2 (3.5 mm stereo), RCA jack (L,R) x 1
Output RCA (L & R) x 1, Network (LAN) RJ-45 x 1 (wired LAN), Control terminals 9-pin D-sub x 1 for RS-232C (serial)
Control 9-pin D-sub x 1 for RS-232C (serial)
Optical system
Motorized zoom, focus and lens shift
Mechanical light shutter
Fixed lens
1.0:1
Zoom lenses
Short zoom 1.5-2.2:1*
Medium zoom 1.9-3.8:1
Long zoom 3.6-6.1:1
Ultra long zoom 6.0-10.3:1
*Lens ships standard

Digital keystone
Horizontal: ± 20 degrees
Vertical: ± 12 degrees
8-point geometry correction
Standard accessories
Power cord (US cord, 1.8m) x 1
(UK cord, 1.8m) x 1
(Euro code, 1.8m) x 1
Computer cable (2m) x 1
HDMI-DVI cable (0.4m) x 1
Wireless remote control x 1 & "AA" Batteries x 2
Security label x 1
Lens cover x 1
Adapter cover x 1
Cable holder x 1
Network and wireless software (in a CD-ROM)
User's manual CD
Optional accessories
Wireless adapter
Hybrid filter
245W UHP lamp
Enhanced feature sets
Crestron RoomView™
AMX Device Discovery
360-degree on axis rotation
Picture-by-picture
Dual-stack control
Digital keystone feature
Hybrid filter up to 20,000 hours maintenance-free
Customizable start-up logo
Selectable aspect ratio 16:9 and true mode
Intuitive graphical user interface
Graphical on-screen lens range
Built-in keypad (power on/standby, menu, up, down, left, right arrows)
Front and rear infrared sensors for IR keypad
Supports simple curved screens
Stackable1design for redundancy or added brightness
Built-in security features and menu settings
Repeatable lens recall capabilities2
16W stereo speakers
1In a stacked setup, this projector is best suited for events or temporary use. The projector may need to be re-aligned if it is used in a fixed-installation application.

2Not available on fixed lenses and does not include zoom or focus capabilities.

Power requirements
Operating voltage: AC100 -120V, 50/60Hz • AC220 -240V, 50/60Hz
Operating current: 3.8A max at 100V AC • 1.9A max at 220V AC
Consumption: • 375W AC100 -120V • 355W AC220 -240V
Dissipation: 1280 BTU/hr @ 100-120V • 1212 BTU/hr @ 220-240V
Dimensions (LxWxH)
Body: (LxWxH): 18.7 x 19.6 x 5.8" (476 x 498 x 147mm) (with standard lens)
Shipping size: (LxWxH): 26.9 x 21.7 x 9.0" (683 x 552 x 229mm)
Weight: 18.7 lbs (8.5kg) (with standard lens)
Shipping weight: 27.1 lbs (12.3kg)
Operating environment
Noise: Standard mode: 35 dBA / 29 dB Eco mode
Temperature: 32-104°F (0-40°C)
Humidity: 10-85% non-condensing
Regulatory approvals
This product conforms to the following regulations related to product safety, environmental requirements and electromagnetic compatibility (EMC)
FCC, Part 15, Subpart B, Class
EN55022/CISPR22 Class A
EN55024 / CISPR24
IEC 60950-1
UL 60950-1
CAN/CSA C22.2 No. 60950-1
Directive (EC) 2002/95/EC (RoHS)
Directive 2002/96/EC (WEEE)
EU Regulation (EC) No. 1907/2006 (REACH)
Certifications marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), C-Tick (Australia and New Zealand), South Africa
Limited warranty
Projector: three years parts and labor
Lamp: 500 hours or one year (whichever comes first)
Contact an authorized Christie representative for full details of our limited warranty

Due to constant research, specifications and features are subject to change without notice
