Luminous Flux:
800 ANSI lumens
Contrast:
10,000:1 dynamic contrast (under LED control)
No mechanical iris required
Uniformity:
95% brightness and colour uniformity after electronic adjustment
Display Technology Type:
Revolutionary solid state projector using a single TI Darkchip 3™ DMD with a solid state illumination engine (no colour wheel) and sealed optics.
Native Resolution:
2560 x 1600 WQXGA
Inputs:
Signal format: 2560 x 1600 WQXGA (VESA RB)
Input frame rate: 60Hz with Single Input
Inputs, Control and Networking:
1 x Dual-link DVI-D
On-board Ethernet control capabilities
Additional Ethernet connections for Christie ArrayLOC™ network
IR/wired remote control as part of optional user kit
2 x RS-232 ports and 1 x RS-422 port
Lens Mount:
Mechanical, horizontal and vertical lens shift
No shutter required
No iris required - user programmable illumination parameters(eliminates the need for a mechanical shutter)
Illumination:
Solid State illumination
RGB
Illumination lifetime greater than 50,000 hours (to 50% output)
Christie ArrayLOC™:
Manages the brightness and colour levels of all projectors within an array to a common level, in real time with no additional latency
Lenses and Lens Offsets1:
0.68:1 fixed lens features ±5% (horizontal) and ±15% (vertical) offset when mounted in landscape orientation
0.80:1 fixed lens features +100%/-60% (horizontal) and +150%/-100% (vertical) offset when mounted in landscape orientation
1.28-1.71:1 zoom lens features +100%/-60% (horizontal) and +150/-100% (vertical) offset when mounted in landscape orientation
Standard Accessories:
Line Cord
Optional Accessories:
0.68:1 WQXGA fixed lens
0.80:1 WQXGA fixed lens
1.28-1.71:1 WQXGA zoom lens
User kit (includes manual, IR remote)
Rugged Motion Platform kit2 to withstand 5g shock load (purpose-built)
Ruggedised transit case
Remote IR sensor
Christie MotoBlend™ optical blending3
Enhanced feature sets:
Minimum Processing Latency (MPL™)
Christie AccuFrame™ smear reduction, fully adjustable in 1% increments to minimum hold time of <6ms
Christie ArrayLOC – automatic, continuous management of brightness and colour-space levels of all projectors in the array to a common level, in real-time
Auto power up
Menus in 5 languages
Power Requirements:
Operating voltage: 100-240V AC @ 50/60Hz
Operating current: 10A max (lower in normal operational modes)
Power dissipation: 2316 BTU/hr max (lower in normal operational modes)
Dimensions:
Dimensions: 400mm x 400mm x 406mm (without lens)
Weight: 40kg (without lens)
Shipping weight: 80kg (without lens)
Operating Environment:
Temperature: 40-95°F (5-40°C)
Humidity: 20-80% non-condensing
Regulatory Approvals:
Directives: (EC) 2002/95/EC (RoHS); 2002/96/EC (WEEE); Regulation (EC) No. 1907/2006 (REACH); CAN/CSA C22.2 No. 60950-1; UL 60950-1; IEC 60950-1; FCC, Part 15, Subpart B, Class A; EN55022/CISPR22 Class A; EN55024/CISPR24; ICEES003 / NMB003 (A)
Certifications marks and product approvals (check with Christie for latest update): cULus (Canada & US); CE (EU); CCC (China); GoST-R (Russia); KC (Korea); PSE (Japan); C-Tick (Australia & New Zealand); South Africa; Mexico
Warranty:
Standard Warranty: Two years parts and labour
Extended Warranty options available
Contact an authorised Christie representative for full details of our limited warranty

1Each offset is specified with the other at zero. Simultaneous horizontal and vertical offsets may limit the adjustment range of each.
2Christie SIM WQ is available with a Ruggedised Motion Platform Kit. These are purpose built to interface with customer's motion platform structures and available on a build to order basis. For details, please contact your Christie sales representative.
3For details, please contact your Christie sales representative.
