10,000 ANSI lumens
10,000 center lumens
10,625 ISO lumens
2,500-10,000:1 FOFO
650:1 ANSI
Contrast aperture
Display technology and resolution
3DLP 0.95"
Full HD (1920 x 1080)
As little as one frame
Input signal compatibility
Native dual-link DVI-D
Frame-doubled 3D - dual-link DVI, VGA
Pixel clock: 330MHz
Scan rates
H - 15 kHz to 120 kHz
V – 23.97 Hz to 150 Hz (up to 120Hz maximum output)*
Inputs, control & networking
RS232 in/out
RS422 in
Ethernet (10/100)
USB device
GPIO (RS232 9-pin male connector)
Built-in backlit LCD keypad
Remote control (with optional wired XLR connection)
Slot 1-2 standard (populated): dual-link DVI-D (330MHz) and VGA (165MHz)
Optional input modules
Analog input card
Slots 3-4 unpopulated
Full bandwidth analog BNC
Dual-link DVI input card (330MHz), VGA (165MHz)
Dual SD/HD-SDI
Video decoder
Twin HDMI
Lens mount and illumination
Motorized horizontal and vertical lens offset
Scheimpflug (tilt) adjustment
Built-in light shutter
Tool-free lens insertion system
All lenses are optional
Dual P-VIP​ 350W lamps
Lamp life: 1500 hrs @350W, 2000 hrs @300W
Lenses (fixed)
Christie ILS lens 0.73:1 SX+ / 0.67:1 HD*
Christie ILS lens 1.2:1 SX+ / 1.1:1 HD
*Maximum refresh rate is 120Hz

Lenses (zoom)
Christie ILS lens 1.25-1.6:1 SX+ / 1.16-1.49:1 HD**
Christie ILS lens 1.5-2.0:1 SX+ / 1.4-1.8:1 HD
Christie ILS lens 2.0-2.8:1 SX+ / 1.8-2.6:1 HD
Christie ILS lens 2.8-4.5:1 SX+ / 2.6-4.1:1 HD
Christie ILS lens 4.5-7.5:1 SX+ / 4.1-6.9:1 HD
Christie ILS lens 7.5-11.2:1 SX+ / 6.9-10.4:1 HD
*Maximum refresh rate is 120Hz

Offsets
+/- 120% Vertical
+/- 54% Horizontal
(* +/-23%V +/- 13%H)
(** +/-70%V +/- 45%H)
Power requirements
Operating voltage: 100 VAC to 240 VAC @ 50/60 Hz
Operating current: 12A @ 100 V
Power: 1320 W
Dissipation: 4508 BTU/hr
Enhanced feature sets
Embedded Christie Twist™ - internal advanced warping and edge-blending
LiteLOC™
Contrast aperture
Dust-sealed, filter-free design
Reduced power requirements (as compared to competitive products on the market today) – at maximum brightness the unit only draws 1320W; standby power consumption (phantom power draw) is less than 20W.
Reduced noise levels
LCD keypad – active keys are amber to indicate whether function selected will be seen by the audience
Motorized yellow notch filter
Built-in portrait display capabilities*
*Christie M Series stacking frame is required in portrait orientation.

Standard accessories
User manual
IR remote
Line cord
Two dual-link DVI-D cards
3D sync cable
Optional accessories
Twin DisplayPort input card​
Coarse dust filter
ILS lens adapter kit
Stacking frame
Dual HD/SDI input card
Twin HDMI input card
Video decoder input card*
*may not include 3D support

Dimensions
Size: (L x W x H): 22.1 x 19.7 x 10.2" (561 x 500 x 259mm)
Weight: 55 lb (25 kg) (without lens)
Shipping weight: 87 lb (38 kg) (without lens)
Operating environment
Operating temperature: 40-104°F (5-40°C)
Humidity (non-condensing): 20-80% non-condensing
Regulatory approvals
UL/CSA/IEC 60950 (3rd edition)
FCC Class A, CE, CCC
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, WEEE
Warranty
3 years parts and labor (including light engine)
