Dual lamp: 12,000 ANSI lumens (14,000 centre lumens)
Single lamp: 6000 ANSI lumens (7,000 centre lumens)
Contrast
2,500:1 (full on, full off)
650:1 ANSI (typical)
Uniformity
90% brightness uniformity
Display type
3-chip 0.95" DMD
Resolution
HD (1920 x 1080)
Lamp type
Dual 450W NSH
Lamp life
High power: 1000 hrs @ 450W
Low power: 1500 hrs @ 360W
Standard inputs
2x Dual-link DVI + VGA
Optional inputs
Analog (5 BNC)
Dual-link DVI
SD/HD-SDI
Video decoder
Twin HDMI
DMX512 interface
Input signals (2D)
HDTV formats VGA through to QXGA (2048 x 1536)
Accepts all current HDTV/DTV formats
Multi-standard video decoder
Horizontal and vertical scaling, all inputs
Input signals (3D)
Native 3D |48-60Hz per eye
Frame doubled 3D | 24-30Hz per eye
Dual input 3D | 48-60Hz per eye
HDMI1.4a | Frame packed and Side-by-Side Horizontal
Pixel clock
330MHz
Scan rates
Horizontal: 15 to 120kHz
Vertical: 23.97 to 150Hz
Inputs, controls and networking
RS232 in/out
RS422 in
Ethernet (10/100)
USB device
GPIO (RS232 9-pin male connector)
Built-in backlit LCD keypad
Remote control (with optional wired XLR connection)
Fixed lenses
ILS Lens 0.67:1 HD*
ILS Lens 1.1:1 HD
Zoom lenses
ILS Lens 1.16-1.49:1 HD**
ILS Lens 1.4-1.8:1 HD
ILS Lens 1.8-2.6:1 HD
ILS Lens 2.6-4.1:1 HD
ILS Lens 4.1-6.9:1 HD
ILS Lens 6.9-10.4:1 HD
Offsets
All lenses ±120% Vertical ±42% Horizontal except those noted below
* 0.67:1 fixed lens ±35%V ±12%H ** 1.16-1.49:1 zoom lens ±100%V ±40%H

Standard accessories
IR remote
Power cord
GPIO 3D sync cable
Optional
accessories
Coarse dust filter
Fog juice filter
Ceiling mount
Ceiling mount extension
ILS lens adapter kit
Stacking frame
Christie AutoStack™ (optional curve module available)
Enhanced
feature sets
LiteLOC™
Comprehensive Color Adjustment (CCA™)
Embedded Christie Twist™ image warping and edge-blending
Intelligent Lens System (ILS™) for zoom, focus, horizontal and vertical offset for all lenses
Auto setup
Digital keystone correction
Menus in five languages
99 channel memories
Black level blending
24/7 operation
Built-in portrait capabilities
Operating voltage
100-240V AC 50/60 Hz
Operating current
15A @ 100V AC
Power
1500W
Dissipation
5,118 BTU/hr
Size
(LxWxH): 22.1 x 19.7 x 10.2" (561 x 500 x 259mm)
Shipping dimensions
(LxWxH): 29.0 x 27.0 x 24.6" (735 x 685 x 625mm)
Weight
55lbs (25kg)
Shipping weight
80lbs (36kg)
Operating environment
Temp: 40 to 104° F (5 to 40° C)
Humidity: 20-80% non-condensing
Regulatory approvals
Directives (EC) 2002/95/EC (RoHS); 2002/96/EC (WEEE); Regulation (EC) No. 1907/2006 (REACH)
CAN/CSA C22.2 No. 60950-1
UL 60950-1
IEC 60950-1
FCC, Part 15, Subpart B, Class A
EN55022/CISPR22 Class A
EN55024 / CISPR24
Certifications marks (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), KC (Korea), PSE (Japan), C-Tick (Australia & New Zealand), South Africa
Limited warranty
3 years parts and labour (including light engine)
Contact an authorised Christie representative for full details of our limited warranty
