Dual lamp: 11,550 centre (10,500 ANSI lumens)
Single lamp: 5775 centre (5250 ANSI lumens)
Contrast
2500-10,000:1 using dynamic iris (full on, full off)
650:1 ANSI (typical)
Display technology and resolution
3-chip 0.95" DLP­
SXGA+ (1400 x 1050) resolution
Lamp
Dual 350W PVIP
High power: 1500 hrs @ 350W
Low power: 2000 hrs @ 300W
Input signal compatibility
HDTV formats VGA through to QXGA (2048 x 1536)
Accepts all current HDTV/DTV formats
Multi-standard video decoder
Horizontal and vertical scaling, all inputs
​Standard Inputs
​Analog (5 BNC)
Dual-link DVI
3G SD/HD-SDI
Video decoder
Scan rates
Horizontal: 15 to 120 kHz
Vertical: 23.97 to 150 Hz
Pixel clock
165MHz
Inputs, controls and networking
RS232 in/out
RS422 in
Ethernet (10/100)
USB device
GPIO (RS232 9-pin male connector)
Built-in backlit LCD keypad
Remote control (with optional wired XLR connection)
Optical system
Dust sealed, 3-Chip DMD light engine
Motorized horizontal and vertical lens offset
Scheimpflug (tilt) adjustment
Built-in light shutter
Tool-free lens insertion system
Fixed lenses
ILS lens 0.73:1 SX+/0.67:1 HD*
ILS lens 1.2:1 SX+/1.1:1 HD
Zoom lenses
ILS lens 1.25-1.6:1 SX+/1.16-1.49:1 HD**
ILS lens 1.5-2.0:1 SX+/1.4-1.8:1 HD
ILS lens 2.0-2.8:1 SX+/1.8-2.6:1 HD
ILS lens 2.8-4.5:1 SX+/2.6-4.1:1 HD
ILS lens 4.5-7.3:1 SX+/4.1-6.9:1 HD
ILS lens 7.3-11.2:1 SX+/6.9-10.4:1 HD
Lens offsets
+/- 100% Vertical
+/- 50% Horizontal
(* ±23%V / ±13%H)
(** ±70%V / ±45%H)
Standard accessories
Analog BNC input card
Dual-link DVI input card
Dual SD/HD-SDI input card
Video decoder
User manual
IR remote
Line cord
Stacking frame
Optional accessories
Coarse dust filter
Fog juice filter
Ceiling mount
Analog BNC input card
Dual-link DVI input card
Dual SD-HD-SDI input card
Video decoder
Twin HDMI™ input card
DMX512 interface card
Enhanced feature sets
LiteLOC™
Comprehensive Color Adjustment (CCA™)
Embedded Christie Twist™ image warping and edge-blending
Intelligent Lens System (ILS™) for zoom, focus, horizontal and vertical offset
Multi-windowing and screen processing (up to a 2x3 array)
Dynamic iris
Menus in five languages
99 channel memories
Auto setup
Digital keystone correction
Dust sealed engine, filter-free design
Motorized yellow notch filter (HD & WUXGA models only)
Built-in portrait display capabilities*
3D upgradable
*Christie M Series stacking frame is required in portrait orientation.

Power requirements
110-240V AC 50/60 Hz operating voltage
13.2 A @100V operating current
1320 W power consumption
4508 BTU/hr dissipation
Dimensions
(L x W x H): 22.1 x 19.7 x 10.2" (561 x 500 x 259mm)
Weight: 55lb (25kg)
Shipping weight: 87lb (39kg)
Shipping dimensions - (LxWxH): 31.3 x 24.2 x 28.1" (795 x 615 x 715mm)
Operating environment
Temp: 40 to 104°F (5 to 40°C)
Humidity: 10-80% non-condensing
Regulatory approvals
UL/CSA/IEC 60950 (3rd edition)
FCC Class A, CE, CCC
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, WEEE
Limited warranty
3 years parts and labour (including light engine)
