• 1U form factor
• Included rack ears
• Optional under table mount
• Optional VESA 'sandwich' mount

Dual DL-DVI (digital only)

• Up to 2560 x 1600 resolution per output
• Support for bezel compensation
• Support for display overlap
• Support for custom resolutions

Dual DL-DVI (digital only)

• Support for 2560 x 1600 (overlay mode using output connectors)
• From 640 x 480 to 1920 x 1080 encoded to H.264

Dual 3.5mm stereo audio

• Analog stereo audio encoded to H.264

Dual mini-USB

• HID device emulation for (soft) KVM control of inputs

Dual Gigabit Ethernet

• 100/1000 Mbps Ethernet, RJ-45 connectors
• Support for IGMPv2, IPv4, IPv6, RTSP, SRTP, HTTP, TCP/IP

• 2 high definition DVI inputs to L5 H.264 video streams at 30Hz
• 2 stereo audio streams
• Support for variable bitrate

• 12 high-definition network video streams @ 30Hz
• Includes borders and labeling
• Up to 20Mbps per video stream
• Direct support for network cameras

• VNC and RDP streams transcoded to H.264

• (WxHxD) 17.40 x 1.74 x 9.5" (442x44x241mm)
• 6.5lbs. (2.95kg)

• 100-240V AC (auto-ranging power supply)
• 4-2A (max)
• 220W (max)
• 750 BTU/hr (max)

• >50,000 hours of major modules

• <15 minutes

• CAN/CSA C22.2 No. 60065 | UL 60065 | IEC 60065 emissions | FCC CFR47, Part 15, Subpart B, Class A – unintentional radiators | EN55103-1 Class A audio, video, audio-visual equipment emission; EN55103-2 audio video, audio-visual equipment immunity; EN61000-3-2, EN61000-3-3 environmental
• Directives: (EC) 2011/65/EU (RoHS); 2012/19/EU (WEEE); Regulation (EC) No. 1907/2006 (REACH)
• Certification marks check with Christie for latest updates): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), KC (Korea), S-Mark (Japan), C-Tick (Australia & New Zealand), Ukraine.

• Designed, manufactured and tested by Christie Digital Systems, USA Inc.'s facility in Phoenix, Arizona, USA

• Limited two years parts and labour
