Projection System

Single Chip DLP Dual LVDS. UHD TRP S610 DMD with XPR technology

Lamp Type / Light Source)

Mercury-free Laser Diode

Native Resolution

4K UHD (3840 x 2160)

Screen Size - Diagonal

100" ~ 130"

Contrast Ratio

Max: 100,000:1 High Contrast Mode

Native: 2,000:1 Typical (Full On/Full Off)

Brightness (ANSI Lumens Max.)

5,000

Colors

1.07 billion

Projector Lens

F-Stop: F/2.74

Focal Length: 2.84mm

Lens Offset: 118%

Throw Ratio

0.189 (wide/tele)

Lamp Hours (Light Source Life)

Up to 20K (Nor)

Keystone Adjustment

Manual Vertical (± 10°) / Manual Horizontal (± 10°)

Four corner adjustment

Audio (Built-in Multimedia Speaker)

2x 6W

Tilt

Front two tilt adjustment wheel (0° ~ 3.6°)

Projector Security

Kensington lock slot

Password protection

Power

1x AC Power

USB

1 x USB-A (3.0) (for PC Free Presentation)

1 x Mini USB-B

HDMI

2x HDMI 1.4a

1x HDMI 2.0 (HDCP 2.2)

Audio Output

1 x Audio out (3.5mm)

Powered USB

2x powered USB Type A (5V / 1.8 A Output)

RS232 port

1 x RS232 (9-pin D-sub)

RJ45 port

1 x RJ45

Bluetooth Audio

Bluetooth 4.2

SPDIF (Digital Audio)

1x SPDIF out

Dimensions (excluding feet)

(WxDxH) mm : 459 mm x 385 mm x 135 mm

(WxDxH) inches : 18.07 inches x 15.16 inches x 5.31 inches

Weight

33.07 lbs (15.0 Kg)

Power Supply

Universal AC 100-240 V 50-60 Hz with PFC

Power Consumption

Normal Mode: 500W ± 15% @ 110Vac

Eco-Mode: 280W ± 15% @ 110Vac

Standby Mode: ≤0.5W

Network Mode: ≤2W

Mounting Options

Front/Rear/Ceiling/Tabletop

Noise

Typical (Normal Mode): 36 dB(A)

Typical (Eco Mode) : 29 dB(A)

Accessories (Optional)

Dell 360 Bluetooth Speaker - AE715

Additional Remote Control

Wall Mount Kit

LAN Display

Yes (Limited to FHD resolution)

PC-Free Presentation

Yes

USB Viewer

Yes

Office Viewer

Yes (Limited to FHD resolution)

Multimedia Viewer

Yes

Audio Projection

Yes

Conference Control

Yes

4-to-1 Split Screen

Yes (Limited to FHD resolution)

Duplicate or Extended Display

Yes (Limited to FHD resolution)

Networking

Yes (Network Display, Crestron, SNMP)

Quick Shutdown

Yes

Aspect Ratio

16:9

Projection Distance

0.33 ft ~ 0.74 ft (101.5mm ~ 227.08mm)

(from Projector Rear to Image)

Hsync Frequency

15K-100KHz

Vsync Frequency

24-120Hz

DLP Chip Type

0.66" UHD TRP S610 DMD, DarkChip3TM

What's in the box

Dell Projector: 1 x Dell S718QL Projector

Power cord: 1 x Power cord (DAO - 9.8ft, ROW - 1.8m)

Cable: 1 x HDMI 2.0 cable (1.8m)

Remote control: 1 x Remote control (Incl. battery)

Batteries: 1 x CR2032 Battery (Spare)

User's Guide & Documentation: USB-key User's Guide

Lamp Hours (Light Source Life)

Lamp life rating is typical time for lamp lumens to diminish by 50% based on lab testing.

Actual operating life will vary and be less under conditions including high use, temperature, dust, or abrupt power-off environments.

Wireless functionality + Advanced features

For PC: PC must have a wireless card or be connected to a wireless network and have the projector software installed for proper function. For Mobile Device: Mobile device must be either iPhone, iPad, Android phone, or Android tablet, and have wireless settings enabled. APP and applications must be downloaded and mobile device connected to Dell projector wireless network for proper function.

Audio Projection

Yes

Warranty

2 Years Advanced Exchange Service, extendable up to 5 years

Your S718QL projector is backed by the 2-Year Advanced Exchange Warranty, and the laser system is covered under the same warranty for up to 20,000 hours of use. If you opt to extend your projectorwarranty1to 3-to 5-years, the laser system is also covered for the term of the warranty, but is still limited to 20,000 hours use.
