Projection System: Epson® 3LCD, 3-chip technology

Projection Method: Front / wall mount

Driving Method: Poly-silicon TFT Active Matrix

Pixel Number: 1,024,000 dots (1280 x 800) x 3

Color Brightness (Color Light Output): 3000 lumens1

White Brightness (White Light Output): 3000 lumens1

Interactive Color Brightness (Color Light Output): 3000 lumens1

Interactive White Brightness (White Light Output): 3000 lumens1

Aspect Ratio: 16:10

Native Resolution: 1280 x 800 (WXGA)

Resize: 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (SXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1366 x 768 (WXGA 60-2), 1440 x 900 (WXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA)

Lamp Type: 230 W UHE (E-TORL®)

Lamp Life:

ECO mode: Up to 6000 hours2
Normal mode: Up to 4000 hours2
Throw Ratio Range: 0.48 – 0.65

Size (projected distance):

53" – 116" without wall mount
68" – 113" with wall mount
Keystone Correction:

Manual:
Vertical: ±7 degrees
Horizontal: ±5 degrees
Contrast Ratio: Up to 3000:1

Color Reproduction: Up to 1.07 billion colors

Color Processing: 10 bit

Projection Lens
Back to top
Type: Digital zoom / Manual focus

F-number: 1.80

Focal Length: 6.48 mm

Zoom Ratio: Digital zoom 1.0 – 1.35

Other
Back to top
Display Performance:

NTSC: 480 lines
PAL: 576 lines
(Depends on observation of the multi-burst pattern)
Input Signal: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM

Interfaces:

Computer / component video: D-sub 15 pin x 2
S-video: Mini DIN x 1
Composite video: RCA (Yellow) x 1
Audio in: RCA x 1 (L and R), Mini stereo x 2
USB connector: Type B x 1 (USB display, audio and pen control)
USB connector: Type A x 1 (USB memory/document camera)
HDMI x 1
RJ-45 x 1
Serial: RS-232c x 1
Monitor out: D-sub 15pin x 1
Audio out: Mini stereo x 1
Microphone: Mini stereo x 1
Wireless LAN port: 802.11 b/g/n
Speaker: 16 W mono

Operating Temperature: 41° to 95° F (5° to 35° C)

Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz AC

Power Consumption:

ECO mode: 254 W
Normal mode: 344 W
Communication on: 6.80 W standby
Communication off: 0.28 W standby
Fan Noise:

ECO mode: 29 dB
Normal mode: 37 dB
Security: Kensington® security lock port, padlock and security cable hole, password protect function

Dimensions
Back to top
Including feet: 13.6" x 11.7" x 6.2" (W x D x H)

Excluding feet: 13.6" x 10.9" x 4.1" (W x D x H)

Weight: 9.1 lb

Remote Control
Back to top
Features: Source search, video, LAN, computer, USB, power, aspect, color mode, volume, e-zoom, A/V mute, freeze, menu, page up and down, help, auto, mouse functions, user, esc, Pen mode

Operating Angle:

Right / Left: ±30 degrees
Upper / Lower: 10 to 70 degrees
Operating Distance: 19.7' (6 m)

Interactive Specifications
Back to top
Interactive Technology: infrared, 940 nm

Interactive Area:

BrightLink 436Wi
68" to 113" diagonal (16:10, WXGA) wall mounted
53" to 116" without mount
Interactive Modes: Computer interactivity/input: Interactive and Whiteboard modes, Dual user

Calibration Method: Automatic or Manual

Interactive Connectivity: USB Type A/B

System Compatibility:

Connection to the computer: USB
Epson Easy Interactive Driver
Windows® and Linux: no driver required
Macintosh®: Mac OS® X 10.3.9, 10.4.x, 10.5.x, 10.6.x, 10.7.x, 10.8.x (Included in the box. Also available for unlimited download at Epson.com support page)
PC-Free Annotation
Back to top
PC-Free Annotation Tools: Yes

PC-Free Annotation Sources: document cameras, DVD/Blu-Ray player, iPod/iPad devices3 (devices not included)

Interactive Software
Back to top
Easy Interactive Tools Compatibility:

System compatibility
Microsoft Windows XP SP2, Windows XP SP3 (Home Edition/Professional), Windows Vista®4, Windows Vista SP14, Windows Vista SP24 (All editions except for Starter), Windows 75, Windows 7 SP15 (All editions except for Starter), Windows 8
Macintosh OS X 10.4.x, Mac OS X 10.5.x, Mac OS X 10.6.x, Mac OS X 10.7.x, Mac OS X 10.8.x
TeamBoard Draw Compatibility : (TeamBoard Draw is included)

System compatibility
Windows XP SP3 (32-bit), Windows Vista (32- or 64-bit), Windows 7 (32- or 64-bit), Quicktime player and Flash player installed
Macintosh Intel Mac OS X 10.5x or later

Interactive Input Device
Back to top

Type of Interactive Input Device: Digital pen (one included)

Multiple Pen Support: Yes6

Interactive Pen Functions: Mouse functions (left and right click), Electronic pen, LED battery status indicator

Interactive Pen Power: AAA batteries, rechargeable

Compatible Pen Battery Types: SANYO eneloop®(HR-3UTG / HR-3UTGA)7, Manganese dry cell, alkaline dry cell

Interactive Pen Dimensions: 6.5" x 0.98" (L x W)

Interactive Pen Weight: 1.2 oz.
