Specifications

Projection System: 3LCD, 3-chip technology

Projection Method: Front / rear / ceiling mount

Driving Method: Poly-silicon TFT Active Matrix

Pixel Number: 1,024,000 (1280 x 800) x 3

Color Brightness (Color Light Output): 2700 lumens1

White Brightness (White Light Output): 2700 lumens1

Aspect Ratio: 16:10

Native Resolution: 1280 x 800 (WXGA)

Resize: 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA) ,1152 x 864 (SXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+)

Lamp Type: 200 W UHE

Lamp Life:

ECO Mode: Up to 6000 hours2
Normal Mode: Up to 5000 hours2
Throw Ratio Range: 1.30 – 1.56

Size (projected distance): 33" – 318" (0.84 – 8.08 m)

Keystone Correction:

Automatic: Vertical: ±30 degrees
Horizontal: Easy-slide
USB Plug 'n Play: PC and Mac® compatible

Contrast Ratio: Up to 10,000:1

Color Reproduction: Up to 1.07 billion colors

Color Processing: 10 bit

Projection Lens

Type: Manual (optical) zoom

F-number: 1.58 – 1.72

Focal Length: 16.9 mm – 20.28 mm

Zoom Ratio: Optical zoom 1.0 – 1.2

Other

Display Performance:

NTSC: 480 lines
PAL: 560 lines
(depends on observation of the multi-burst pattern)
Input Signal: NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM

Interfaces:

HDMI x 1
Computer / Component video: D-sub 15 pin x 1
S-video: Mini DIN x 1
Composite video: RCA x 1
USB connector: Type A x 1 (PC-free and other)
USB connector: Type B x 1 (USB Plug 'n Play)
Speaker: 1 W (Mono)

Operating Temperature: 41° to 95° F (5° to 35° C)

Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz

Power Consumption:

ECO mode: 207 W
Normal mode: 283 W
Fan Noise:

ECO mode: 29 dB
Normal mode: 37 dB
Security:

Kensington®-style lock provision
Security anchor bar

Dimensions

Including feet: 11.6" x 9.0" x 3.1" (W x D x H)

Excluding feet: 11.6" x 9.0" x 3.0" (W x D x H)

Weight: 5.1 lb

Remote Control

Features: Source search selection, power, volume, e-zoom, A/V mute, freeze, menu, page up and down, help, auto, mouse functions

Operating Angle:

Right / Left: ±30 degrees
Upper / Lower: ±15 degrees
Operating Distance: 19 ft. (5.8 m)

Notes

1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

2 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.

Epson projectors have 3x Brighter Colors than their leading competitive 1-chip DLP business and education projectors. Competitive projectors based on NPD data, July 2011 through June 2012. Color brightness (color light output) measured in accordance with IDMS 15.4. Color brightness will vary depending on usage conditions.
