Optical
LCD Panel
0.59" (1.5cm) P-Si TFT x 3

Resolution
WXGA (1280 x 800)

Light Output (Brightness)
2500 ANSI Lumens (Normal Mode)/1600 ANSI Lumens (Eco Mode)

Brightness
2500 ANSI Lumens (Normal Mode) / 1600 ANSI Lumens (Eco Mode)

Contrast Ratio
4000:1

Lens
Free shaped lens & motorised free shaped mirror

Lamp Wattage
215 W

Lamp Life
3000 Hours (Bright Mode)/5000 Hours (Normal Mode)*

Focus distance
0.4m~0.7m (from mirror top to screen plane)

Distance to width ratio
0.3:1 (fixed)

Diagonal display size
60~100" (152~254cm)

Number of colours
8 Bit/colour, 16.7M colours

Keystone
Fixed, 5.2:-1 upward shift, Normal at +68.3° projection angle

Compatibility
Computer compatibility
IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA (compressed), MAC 16"

Composite Video
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43

Component Video
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 1125p(1080p@50/60), 750p(720p@50/60)

HDMI
1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

Plug & Play
DDC2B

Features
Speakers
16W x 1 (Mono)

Basic functions
Freeze, Magnifying, Blank, Auto adjustment, Mirror reverse image, Up-side down image, Auto signal search

Picture Adjustments
Digital Zoom x 1.35, Equalising Digital Gamma Correction, 2-3 pull down for NTSC, Progressive Scan, Noise reduction, Aspect selection 4:3/16:9/16:10/14:9/Native - dependant on source, Equalising colour temperature adjustment, Perfect Fit

Digital keystone
Horizontal ±5°, Vertical ±5°

Advanced Features
Drawing function (optional wireless tablet TB-1 required), My Screen,My Memory, My Button by remote control, My Source, My Text, Picturemode (8 modes), Source naming (English), Resolution setting, Template, Saving mode, Audio pass through, Cloning, Audio soundmixing, Audio out (standby) and monitor out/selectable source with menu, Eco Mode (Normal, Eco, Intelligent Eco, Saver), Filter timer/selectable interval time, PC-less Presentation (JPEG, PNG, BMP,GIF, AVI, MOV), Stand-by Audio, Template, On screen installation guide, iOS Connectivity

Outward
Easy Lamp replace from Top, Rear intake air filter

Power on & off
Direct On, Auto Off, Auto Eco Mode

Security Systems
PIN Security Lock, Myscreen Password Lock, Transition Detector, My Text Password Lock, Key Lock (key pad, remote control), Kensington slot, Security bar, Lens door lock

Network (A222)
Configure and control projector via web browser, Failure and warning alerts via e-mail, Scheduling, My Image (still image transfer display), Displaying text data transferred via the network, Command Control via network, Crestron RoomView® (not accessible through wireless adapter), AMX Device Discovery, Projector management via SNMP,P J Link™, Network Bridge, Network Presentation (PC still picture transfer), MAC address on side, USB Display

OSD languages options
33, including: English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Swedish, Russian, Finnish, Polish, Turkish, Arabic, Czech, Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian

Connections
Digital input
1 x HDMI (HDCP compatible)

Computer Input
2 x 15-pin Mini D-sub

Monitor output
15-pin Mini-D-sub x 1

Video Input
1 x RCA Jack (for composite)
1 x S-Video Jack
2 x Component D-sub (shared with analogue computer in 1/2)

Audio Input
2 x Stereo Mini Jack
1 x pair RCA (L/R)
1 x Microphone Jack

Audio output
1 x pair RCA (L/R)

Control
1 x 9-pin D-sub for RS232 control

USB
2 x USB type A
1 x USB type B

Wired network
1 x RJ-45

Wireless network
Option, IEEE802.11b/g/n ready (optional wireless adapter required)

Power
Power Supply
AC100-120 / 220-240 V, auto switching

Power Consumption/Standby
310W (AC220-240V)/<0.35W

Physical
Dimensions (W X H X D)
345 x 85 x 303mm (excluding feet and extrusions when mirror is closed)

Weight
3.8Kg

Noise Level
34dB (Bright)/28dB (Normal)

Ambient temperature
Operating 0°C~40°C, Storage -20°C~60°C

Air Filter
Hybrid

Miscellaneous
Misc A222
Lamp indicator light, power light, ceiling mount image, rear projection image, serial number label on side, Tabletop use (optional stand is required)

Certification
Cert A222
UL60950-1/ cUL, FCC Part15 subpart B class B, CE Marking: EN61000-3-2, EN61000-3-3, EN55022(class B), EN55024(EMC directive), EN60950-1 (Low voltage directive), WEEE/RoHS, /ErP(lot6) compliant, c-tick class B (Australia/New Zealand), GOST-R (Russia)

Accessories Supplied
Acc A222
Remote control with batteries, RGB cable, power cord, cable cover, security label, user manual (detail & concise), Application CD, Wall mount (HAS-K252), Adapter cover

Optional Accessories
Replacement lamp
DT01381

Table top stand
TT-251

Wireless pen tablet
TB-1

Interactive camera unit
IM-1

USB wireless adapter
USB-WL-11N

Warranty
Projector warranty
3 Years

Lamp warranty
6 Months/5000 Hours**

disclaimer 3years /6 months
*The stated lamp and filter life refers to the average life expected in ideal operating conditions with usage in accordance with the manual. The majority of, but not all lamps and filters should achieve this figure. **Where a lamp fails within warranty and a replacement lamp is taken, the warranty for the replacement lamp will be a maximum of 6 months (dependent on warranty hours stated).
