Optical
LCD Panel
0.59" (1.5cm) P-Si TFT x 3

Resolution
WXGA (1280 x 800)

Brightness
Normal Mode 2600 ANSI Lumens
Eco Mode 1700 ANSI Lumens

Contrast Ratio
3000:1

Lens
Manual focus, digital zoom x 1.35

Lamp Wattage
225W UHP

Lamp Life
3000 Hours (Normal Mode) / 5000 Hours (Eco Mode)*

Focus distance
0.735m ~ 1.953m

Distance to width ratio
1:0.6

Diagonal display size
60~150" (152~381cm)

Keystone correction
Fixed 5.6:-1 upward shift, Normal at + 36.6° projection angle

Number of colours
8 Bit/colour, 16.7M colours

Compatibility
Computer compatibility
IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA (compressed), MAC 16"

Composite/S-Video
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43

Component Video/HDMI
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

Plug & Play
DDC2B

Features
Speakers
10W x 1 (mono)

Basic functions
Freeze, Magnify, Blank, Aspect selection, Auto signal search, Auto eco mode

Picture Adjustments
2-3 Pull Down for NTSC, Digital image shift (vertical), Equalizing colour temperature adjustment, Equalizing digital gamma correction, Mirror reverse image, Up-side down image, Video noise reduction

Digital Keystone Correction
Vertical: ±5°

Advanced features (CX300WN/CP-CW250WN/CP-CW300WN)
Audio ports assign, Closed Caption (for NTSC & 480i), Drawing function (requires TB-1 wireless interactive tablet, Eco Mode (Normal, Eco, Intelligent eco, Saver), Filter timer, Frame Lock, My Button by Remote control, My Memory, My Source, My Text, MyScreen, Overscan, PC-less Presentation, Picture mode (Normal, Cinema, Dynamic, Board (Black), Board (Green), Whiteboard, Daytime, Photo), Progressive scan, Resolution setting, Source naming (English), Stand-by audio, Template, USB Display, ImageCare™, Cloning function, iOS connectivity, Android connectivity

Outward
Lamp replace from top, Filter replace from side

Power on & off
Direct power on, Auto power off

Security Systems
Security bar, PIN security lock, MyScreen password lock, My text password lock, Key lock (keypad, remote control), serial number on front of projector, Kensington slot

Network
AMX Device Discovery, Command Control via the Network, Configuring and Controlling the Projector via a Web Browser, Controlling the Projector via Scheduling, Crestron RoomView® (Not accessible through the wireless adapter), Displaying text data transferred via network, Failure and Warning Alerts via E-mail, My Image (still image transfer) Display, Network Bridge, Network Presentation (PC still picture transfer), PJLink™, Projector Management via SNMP

OSD Languages
English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkish, Arabic, Persian, Czech, Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian, Thai, Portuguese (Brazil), Indonesian, Vietnamese

Connections
Digital input
1 x HDMI

Computer Input
2 x 15-pin Mini D-sub

Computer output
1 x 15-pin Mini D-sub

Video Input
1 x RCA composite, 1 x S-Video, 2 x component (shared with analogue computer in 1/2)

Audio Input
2 x Stereo Mini Jack, 1 x pair RCA (L/R), 1 x Microphone Jack

Audio output
1 x pair RCA (L/R)

USB
2 x USB type A (PC-less presentation or optional wireless adaptor)
1 x USB type B (USB mouse control or USB display)

Control
1 x 9-pin D-sub for RS232C Control

Wired network
1 x RJ-45

Wireless LAN
Optional wireless adapter required

Power
Power Supply
100-120V/220-240V, auto switching

Power Consumption/Standby
300W/

Dimensions (W X H X D)
345 x 85 x 303mm (excluding feet and extrusions)

Weight
3.6Kg

Noise Level
30dB (Eco Mode)/37dB (Normal Mode)

Operating Temperature
0~40°C

Air Filter
Hybrid (up to 5000 hours)

Miscellaneous
Miscellaneous
MAC address displayed on the front of projector

Certification
Certification (CP-CX250)
UL, CB, GS, AUS, Fcc, c-tick, CE, DoC

Accessories Supplied
Accessories Supplied (CP-CX300WN/CP-CW250WN/CP-CW300WN)
Remote control with batteries (HL02881), Computer cable, Power cord, Lens cover, USB wireless adapter cover, User manual (detail & concise), Security label, Application CD

Optional Accessories
Replacement lamp
DT01511

Filter
UX37191

USB wireless adapter
USB-WL-11N

Solution product
TB-1 Wireless interactive tablet

Interactive camera unit
IM-1

Wireless multi-functional switcher
MS-1WL

Warranty
Projector warranty
3 Years

Lamp warranty
6 Months**

Lamp warranty ( education )
For education and extended warranties please contact your local dealer

disclaimer 3years /6 months
*The stated lamp and filter life refers to the average life expected in ideal operating conditions with usage in accordance with the manual. The majority of, but not all lamps and filters should achieve this figure. **Where a lamp fails within warranty and a replacement lamp is taken, the warranty for the replacement lamp will be a maximum of 6 months (dependent on warranty hours stated).
