Optical
LCD Panel
0.59" aspect ratio 16:10

Resolution
WXGA (1280 x 800)

Brightness
2600 ANSI Lumens (Normal Mode) / 2132 ANSI Lumens (Eco Mode 1) / 1742 ANSI Lumens (ECO mode 2)

Contrast Ratio
10,000:1

Lens
Manual focus, digital zoom x 1.35

Lamp Wattage
225W UHP

Lamp Life
5000 hours (Normal Mode) / 8000 hours (Eco Mode 1) / 10,000 hours (Eco Mode 2)

Focus distance
0.735m ~ 1.953m

Distance to width ratio
1:0.6

Diagonal display size
60 -150"

Keystone correction
Fixed 5.6:-1 upward shift, Normal at + 36.6° projection angle

Number of colours
16.7 million

Compatibility
Computer compatibility
IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed), MAC16"

Composite/S-Video
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43

Component Video/HDMI
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

Plug & Play
DDC2B

Features
Basic functions
Freeze, Magnifying, Blank, Auto signal search, Auto eco mode

Picture Adjustments
2-3 Pull Down for NTSC, Digital image shift (vertical), Equalizing colour temperature adjustment, Equalizing digital gamma correction, Mirror reverse image, Up-side down image, Video noise reduction

Advanced Features
Audio ports assign, closed caption (for NTSC & 480i), drawing function (requires TB-1 wireless interactive tablet, Eco Mode (Normal, Eco, Intelligent eco, Saver), filter timer, frame lock, My Button by remote control, My Memory, My Source, My Text, MyScreen, overscan, PC-less presentation, picture mode (normal, cinema, dynamic, board (black), board (green), whiteboard, daytime, photo), progressive scan, resolution setting, source naming (English), stand-by audio, template, USB Display, ImageCare™, cloning function, iOS connectivity, Android connectivity

Outward
Easy lamp replace from top, Easy access air filter

Power on & off
Direct on, Auto off

Security Systems
Password/My Screen Password, PIN lock, Key lock

Network
Project Monitoring (Wired LAN), Control from Remote Location (Wired LAN), E-mail Alerts (Wired LAN), mirroring of PC Screen (used the LiveViewer soft), infrastructure mode (Wireless LAN), Adhoc mode (Wireless LAN), SNMP Management (SNMP), cloning function, easy schedule setting

OSD Languages
English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkish, Arabic, Persian, Czech, Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian, Thai, Portuguese (Brazil), Indonesian, Vietnamese"

Connections
Digital input
HDMI (HDCP compliant) x 2

Computer Input
2 x 15-pin Mini D-sub

Monitor output
1 x 15-pin Mini D-sub

Video Input
RCA connector x 1

Audio Input
3.5mm stereo mini connector x 2, 1 x pair RCA (L/R)

Audio output
3.5mm stereo mini connector x 1

Control
1 x 9-pin D-sub for RS-232C control

Wired network
1 x RJ-45

Wireless LAN
Optional wireless adapter required

USB
2 x USB type A, 1 x USB type B

Physical
Dimensions (W X H X D)
345 x 85 x 303mm (excluding feet and extrusions)

Weight
3.6Kg

Noise Level
37dB (Normal Mode) / 32 dB (Eco1) / 29dB

Air Filter
Hybrid (up to 5000 hours)

Power
Power Supply
100-120V/220-240V, auto switching

Power Consumption/Standby
320W/0.35W (AC 220-240V)

Accessories Supplied
Accessories Supplied
Power cable, computer cable, remote control with batteries, lens cover and cap, adapter cover (for USB Wireless Adapter), Security label, user's manual CD, user's manual book, application CD

Certification
Certification
UL, CB, GS, AUS, FCC, C-TICK, CE, DOC

Optional Accessories
Replacement lamp
DT01511

USB wireless adapter
USB-WL-11N

Remote Controller
HL03031

Warranty
Warranty
3 Years / 6 Months (for education and extended warranties please contact your local dealer.)
