Optyka
Panel LCD
0.63 inch 3LCD Panel

Rozdzielczość
XGA (1024 x 768)

Jasność
3200 ANSI Lumens (Normal) / 2624 ANSI Lumens (Eco 1) / 2144 ANSI Lumens (Eco2)

Colour light output (colour brightness)
3200 ANSI Lumens (Normal), 2624 ANSI (ECO1), 2144 ANSI (ECO2)

Współczynnik kontrastu
2000:1

Lamp Life (Hours)
5,000 hours (Normal) / 10,000 hours (Eco-2)

Obiektyw
Manual Zoom x1.2, Manual Focus

Focus Distance
0.9m ~ 9.1m (Wide), 1.0m ~ 10.9m (Tele)

Stosunek odległości do szerokości ekranu
1,5 (szerokokątny), 1,8 (teleobiektyw)

Wielkość obrazu
30 cali–300 cali

Liczba kolorów
16.7 million colours

Zgodność
Zgodność komputera
IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/WSXGA+/UXGA/WUXGA (compressed), MAC16"

Composite
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43

Component Video
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

Sygnał wideo HDMI
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

Plug & Play
DDC2B (VESA) for Computer in1 DDC2B (VESA) for HDMI

Cechy i funkcje
Głośniki
16w Mono

Cyfrowa korekcja trapezu
±30 stopni w pionie

Picture Modes
Normal, Cinema, Dynamic, Board (Black), Board (Green), Whiteboard, Daytime, Photo

Basic Features
ASPECT selection for data Normal / 4:3 / 16:9 / 16:10, for HDMI Normal / 4:3 / 16:9 / 16:10 / 14:9, for Video 4:3 / 16:9 / 14:9, Audio pass through, Audio ports assign, Audio out (standby) and monitor out / selectable source with MENU, Auto eco mode, Auto power off, Auto signal search; direct power on; equalizing colour temperature adjustment, Equalizing digital gamma correction; frame lock (data signal with vertical frequency of 49 to 51 Hz, 59 to 61 Hz), Image blank by RS232C/Remote control, LED lamps (power, lamp, temp), Magnify 4 times (XGA) by RS232C / remote control, Mirror reverse image, Up-side down Image, MyButton by remote control, MyMemory, MySource, MyText, MyScreen, Overscan (video, component video signal), Picture freeze by RS-232C / remote control; serial number displayed on EASY MENU and on the side of projector. Source naming (in English), Stand-by audio

Network (LAN only)
AMX device discovery, Command control via the network, Confi guring and controlling the projector via a web browser, Controlling the projector via scheduling, Crestron RoomView®, Failure and warning alerts via e-mail, Network bridge, PJLinkTM

Security
PIN security lock, MyScreen password lock, MyText password lock, Key lock (key pad, remote control)

Języki menu ekranowego
33

Złącza
Digital input
HDMI x 1

Analog Input
15-pin Mini D-sub x 2, RCA jack x 1

Monitor Output
15 pin D-Sub shrink x 1

Wejście audio
3.5 mm stereo mini jack x 2 RCA jack(L/R) x 1

Wyjście audio
Złącze RCA (L/P) x 1

Wireless LAN (Adapter not included) / Wired LAN
no / RJ45

USB Type A
No

USB typu B
Used for remote control mouse

Moc
Zasilanie
AC 100 - 120 V / AC 220 - 240 V (50/60 Hz)

Power Consumption/Standby
AC 220 - 240 V / 330 - 310 W /

Parametry fizyczne
Masa
3 kg

Wymiary (szer. x wys. x głęb.)
320 x 85 x 245 mm

Poziom hałasu
37 db (Normal), 32db (ECO-1), 29db (ECO-2)

Air Filter (Unwoven)
5,000 hours

Akcesoria w zestawie
Akcesoria w zestawie
Power cord - EU model: 1 x 1.8 m EU cord / US model: 1 x 1.8 m US cord, 1 x 2 m computer cable, 1 x IR remote control unit, 2 x AA batteries, User's manual CD (operating guide, network function, 1 x safety instructions, 1 x User's manual (concise)

Remote Control with Batteries
HL03033

Opcjonalne Akcesoria
Lampa zamienna
DT01481

Gwarancja
Warranty
3 years / 3 years (for education and extended warranties please contact your local dealer)
