OPTICAL

Panel 0.96" (2.4cm) DMD x 3
Resolution WUXGA (1920 x 1200)
Brightness Normal Mode 13,000 ANSI Lumens
Eco Mode 10,060 ANSI Lumens
Contrast ratio 2000:1
Standard Lens Lens not supplied (see optional lenses)
Lamp 465W x 2 (Normal Mode)/360W x 2 (Eco Mode)
Lamp life 2000 hours (Normal Mode)/2500 hours (Eco Mode)*1
Diagonal display size 100"~400" (2.54m~10.16m) (Standard lens: ML-K04)
Lens shift Vertical: -25~+50% (excluding FL-K01 optional lens)
Horizontal: -10~+10% (excluding FL-K01 optional lens)
Number of colours 1.07 billion colours
Focus distance 4.0m~24m (Standard lens: ML-K04)
Distance to width ratio (:1) 1.87~2.56 (Standard lens: ML-K04)
COMPATIBILITY

Computer compatibility IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, WSXGA+, UXGA, WUXGA, MAC 16"
Component Video 525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 1125p(1080p@50/60), 750p(720p@50/60)
3D DVI 1920x1080@120Hz, 1920x1080@100Hz, 1920x1080@60Hz, 1920x1200@120Hz, 1920x1200@100Hz, 1920x1200@60Hz
SDI NTSC, PAL, 1035i@60Hz, 1080i@59Hz, 1080i@60Hz, 1080P@30Hz, 1080P@25Hz, 1080i@50Hz, 1080P@24Hz, 720P@60Hz, 720P@50Hz, 1080Sf@25Hz, 1080Sf@30Hz, 1080P@50(3G_A*2), 1080P@59(3G_A), 1080P@60(3G_A), 1080P@50(3G_B), 1080P@59(3G_B), 1080P@60(3G_B)
Plug & Play DDC2B
FEATURES

Basic functions Auto signal search
Picture adjustments Aspect selection, Mirror reverse image, Progressive scan
Digital keystone correction Vertical ±20°, Horizontal ±35°
Advanced features 3D display, Edge blend, Framelock, Gamma correction selection, Lamp mode (Normal, Eco, power), Picture by Picture, Picture in Picture, Shutter by remote control, Warp (geometric correction), Dual lamp, DICOM Simulation Mode
Power on & off Auto off
OSD languages English, French, German, Spanish, Japanese, Simplified Chinese, Traditional Chinese, Korean, Portuguese
CONNECTIONS

Digital input 2 x HDMI (HDCP compatible), 1 x 3D DVI, 1 x SDI
Digital output 1 x SDI
Computer input 1 x 15-pin Mini D-sub, 1 x 5 BNC
Video input 1 x 3 RCA, 1 x 15-pin Mini D-sub, 1 x 5 BNC
USB 1 x USB Type B
3D sync 1 x BNC (in), 1 x BNC (out)
12V trigger 2 x Stereo mini jack
Control 1 x 9-pin D-sub for RS-232C
Network 1 x RJ-45
POWER

Power supply AC90-143V / AC180-264V (50/60Hz)
Power consumption/Standby 1250W/PHYSICAL

Dimensions (W x H x D) 500 x 633 x 270mm (excluding feet and extrusions)
Weight 34kg (excluding lens)
Ambient temperature Operating: 0~40°C/Storage: -20~60°C
Noise level 46dB (Normal Mode)/42dB (Eco mode)
Filter Hybrid (up to 1000 hours)
CERTIFICATION

UL60950-1/cUL, FCC Part 15 subpart B class A, CE Marking: EN61000-3-2, EN61000-3-3, EN55022, EN55024 (EMC Directive), EN60950-1 (Low voltage directive), WEEE/RoHS/ErP (lot6, lot19) compliant, TUV GS, RCM class A, EAC
ACCESSORIES SUPPLIED

Remote control with batteries (HL03051), Power cord, RS-232C cable, EAC document, User manual (CD-ROM & printed sheet)
OPTIONAL ACCESSORIES

Replacement lamp DT01591D
Ultra short throw lens FL-K01
Short throw lens FL-K02
Short throw zoom lens SL-K03
Standard zoom lens ML-K04
Long throw zoom lens LL-K05
Ultra long throw zoom lens UL-K06

Optional Lenses

FL-K01 Short Fixed Lens
Throw Ratio 0.70:1
FL-K02 Fixed Lens
Throw Ratio 1.10:1
LL-K05 Long Zoom Lens
Throw Ratio 2.60:1-4.20:1
ML-K04 Standard Zoom Lens
Throw Ratio 1.90:1-2.60:1
SL-K03 Zoom Lens
Throw Ratio 1.40:1-1.90:1
UL-K06 Ultra Long Zoom Lens
Throw Ratio 4.20:1-7.00:1

WARRANTY

Projector/Lamp 3 Years/6 Months**
*1. The stated lamp life refers to the average life expected in ideal operating conditions with usage in accordance with the manual. The majority of, but not all lamps and filters should achieve this figure. *2. 3G_A=3G LEVEL A, 3G_B=3G LEVEL B *3. Where a lamp fails within warranty and a replacement lamp is taken, the warranty for the replacement lamp will be a maximum of 6 months (dependent on warranty hours stated).
