Optyka
Wyświetlacz
0.67" (16:10 aspect ratio) DLPx1

Rozdzielczość
WUXGA (1920 x 1200)

Jasność
10000 ANSI Lumens (Normal Mode) / 7500 ANSI Lumens (Eco Mode)

Współczynnik kontrastu
2500:1

Obiektyw
Interchangeable, Powered Zoom, Powered Focus, Lens shift

Moc lampy
430W Dual (Normal) / 344W Dual (ECO)

Trwałość lampy
2000 godzin (tryb zwykły)/4000 godzin (tryb eko)*

Współczynnik odległości do szerokości
1.6 (WIDE), 2.4 (TELE) (Standard Lens SD-903 not included)

Przekątna obrazu
50"~600" (100" at 3.5m, wide max.)

Liczba kolorów
16.7 million colours

Ogniskowa
1.8m~21.4m (WIDE) / 2.7m~31.9m (TELE) (Standard Lens SD-903 not included)

Korekcja geometrii obrazu
Vertical 11:-1, Normal at +12.9°~+8.7° projection angle

Zgodność
Computer compatibility
IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/WSXGA+/UXGA/WUXGA (compressed), MAC16"

Composite Video
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43

Component Video
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 1125p(1080p@50/60), 750p(720p@50/60)

HDMI/HDBaseT/SDI
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

Cechy i funkcje
Podstawowe funkcje
Auto signal search & Source skip,Frame Lock,Image blank by RS232C/Remote control LED lamps (Filter, Shutter, Security, Lamp-1, Lamp-2, Temp, Power),Mechanical shutter, Magnify, Mirror Reverse Image, Up-side Down Image, Freeze, Serial number displayed on EASY MENU and on the side of projector, Status monitoring by sub LCD

Picture Adjustments
Bright/Rich Colour, Accentualizer and HDCR, Equalizing Colour temperature adjustment, Equalizing Digital Gamma Correction, Picture mode (Standard, Natural, Cinema, Dynamic, Board (Black), Board (Green), Whiteboard, Daytime, DICOM Simulation, User-1, User-2, User-3), Resolution setting, Video noise reduction, Mirror Reverse Image, Up-side Down Image, My Button by Remote control, My Memory, My source, My Text, MyScreen

Cyfrowa korekcja trapezu
Horizontal & Vertical ± 30 degrees

Advanced Features
360 degree installation angle, Active Iris,Blending/Cropping,Filter timer / selectable interval time to show the message for air filter cleaning,Image blank by RS232C/Remote control,Lens memory (Lens shift position, Lens type) MAC address displayed on the side of projector,Magnify 4 times (XGA) by RS232C/ Remote control, Mechanical shutter, Overscan (Video, Component video signal), Perfect Fit (4 corners), capable of saving/loading the setup, Picture by Picture/Picture in Picture, Magnify 4 times (XGA) by RS232C/Remote control, Portrait projection,Resolution setting,Warping and Blending Simultaneously, Scheduling features, 24/7 Dual Lamp mode

Włączanie i wyłączanie
Auto Power off, Direct power on, Eco mode

Security Systems
PIN Security Lock, MyScreen Password Lock, My Text Password Lock, Lens Lock, Key Lock (Key pad, Remote Control)

Sieć
AMX Device Discovery, Command Control via the Network, Configuring and Controlling the Projector via a Web Browser, Controlling the Projector via Scheduling Crestron RoomView® (Not accessible through the wireless adapter), Displaying text data transferred via network, Extron XTP system, Failure and Warning Alerts via E-mail, My Image (still image transfer) Display, Network Bridge, Network Presentation (PC still picture transfer), Frame rate (practical) is under 12fps (640x480 movie) reference purpose only, PJLinkTM, Projector Management via SNMP

Języki menu ekranowego
33

Złącza
HDMI Input
2 x HDMI (zgodne z HDCP)

Wejście komputerowe
Mini-D-Sub 15-pin connector x 1

Wyjście monitora
15-stykowe złącze mini D-sub x 1

Wejście DVI-D
1 x DVI-D

SDI
1x SDI input

Standard HDBaseT
1x HD Base T input

Composite video (RCA jack)
1 x BNC

Sterowanie
1 x RS-232C

USB typu A
1

Pilot zdalnego sterowania na kablu
1 x 3.5mm

Sieć przewodowa
Przewodowa sieć LAN (RJ45)

Wireless network
Wireless LAN (USB WLAN Dongle, USB A) Optional

Moc
Zasilanie
110-120V AC 10.2A / 220-240V AC 5.6A

Power Consumption/Standby
110-120V AC 1090W / 220-240V AC 1070W / Standby 0.5W

Parametry fizyczne
Wymiary (szer. x wys. x głęb.)
537 x 505 x 170mm (with SD-903 lens) / 537 x 438 x 170mm (without lens)

Masa
17.099kg (no lens) / 18.299kg (SD-903; Standard zoom Lens)

Poziom hałasu
37dB (Normal) / 32dB (Eco)

Filtr powietrza
Hybrydowy (do 15 000 godzin)

Certyfikacja
Certyfikacja
EMC, Low Voltage, ErP, RoHS, CE

Akcesoria w zestawie
Akcesoria w zestawie
Remote Control HL02804, Power cord: US cord (3m) x 1, Euro cord (3m) x 1, Computer Cable (2m) x 1, Wireless USB Cover x 1, Wireless Remote Control Unit x 1, Ferrite core and Band x 2, Cable tie, AA Batteries x 2, Security Label x 1, Application CD x 1, User's Manual CD (Safety Guide, Quick Setup Guide, Network Quick Setup Guide, Operating Guide, Instant Stack Guide, Network Guide, ) x1, User's Manual (Concise) x1

Opcjonalne Akcesoria
Akcesoria opcjonalne
USB Wireless adaptor USB-WL-11N, Lamp DT01911, Filter set UX39551

Obiektyw
FL-910 (Ultra Short Throw Lens), USL-901 (Ultra Short Throw Lens), SL-902 (Short Throw Lens), SD-903 (Standard Lens), ML-904 (Middle Throw Lens), LL-905 (Long Throw Lens), UL-906 (Ultra Long Throw Lens)

Gwarancja
Warranty
3 years Projector / 6 month Lamp
