Optional Accessories
Replacement Lamp
DT01481

USB Wireless Adapter
USB-WL-11N

Remote Controller
HL03031

Warranty
Warranty
3 years Projector / 6 month Lamp

Miscellaneous
Miscellaneous
Indicator lights (lamp, temp, power), Ceiling mount image, Rear projection image, Serial number label on side, MAC address label on side, MAC PC support

Certification
Certification
UL60950-1/CUL, FCC PART 15 SUBPART B CLASS B, CE MARKING: EN61000-3-2, EN61000-3-3, EN55022 (CLASS B), EN55024 (EMC DIRECTIVE), EN60950-1 (LOW VOLTAGE DIRECTIIVE), WEEE, ROHS, ERP (LOT 6) COMPLIANT, GS MARK, C-TICK CLASS B (STANDARD FOR AUSTRALIA/NEW ZEALAND.)

Accessories Supplied
Accessories Supplied
Power cable, computer cable, remote control with batteries, lens cover and cap, adapter cover (for USB Wireless Adapter), Security label, user's manual CD, user's manual book, application CD

Physical
Dimensions (W X H X D)
320 x 85 x 245mm (excluding feet and extrusions)

Weight
3.0Kg

Noise Level
37dB (Normal Mode)/32 dB (ECO1 mode), 29dB (ECO2 mode)

Air Filter
Unwoven fabric, replacement cycle: 5000hr (varies according to usage environment)

Power
Power Supply
100-120V/220-240V, auto switching

Power Consumption/Standby
310W/

Connections
Digital Input
HDMI (HDCP compliant) x 2

Computer Input
Mini-D-Sub 15-pin connector x 2

Monitor Output
Mini-D-Sub 15-pin connector x 1

Video Input
RCA connector x 1

Audio Output
3.5mm stereo mini connector x 1

USB Type A
USB Type A x 2 (PC less) Presentation or Wireless adaptor

USB Type B
USB type B x 1 (USB display, or USB mouse control)

Wired Network
1 x RJ-45

Wireless Network
IEEE801.11 b/g/n ready (optional USB wireless adapter required)

Control
1 x 9-pin D-sub for RS-232C control

Features
Basic Functions
Freeze, Magnifying, Blank, Auto adjustment, Search, Page Up & Down (for USB mouse function), Auto signal search, Auto eco mode

Picture Adjustments
Aspect selection (video, data, HDMI), Equalizing Digital Gamma Correction, Equalizing Colour temperature adjustment, 2-3 pull down for NTSC, Mirror reverse image, up-side down image, Progressive Scan, Noise Reduction, Overscan

Digital Keystone Correction
Horizontal & Vertical ± 30 degrees

Advanced Features
Accentualizer, HDCR, audio pass through, cloning, auto signal search, perfect fit, PC less presentation, ECO -1, ECO -2, Myscreen, My memory, My button, My text, My source, picture modes (normal, cinema, dynamic, blackboard, whiteboard, greenboard, photo), daytime mode, input source naming (English), resolution setting, template, Closed Caption (for NTSC & component 480i only), audio pass through, framelock, audio ports assign, cloning, drawing function (optional wireless pen tablet TB-1 is necessary), eco mode (normal, eco intelligent eco, saver), iOS Connectivity, ImageCare ™

Outward
Easy lamp replace from top, Easy access air filter

Power On & Off
Direct on, Auto off

Security Systems
Pin Security Lock, Myscreen Password Lock, Transition Detector, My Text Password lock, key lock (key pad, remote control)

Network
Project monitoring (Wired LAN), control from a remote location (Wired LAN), E-mail alerts (Wired LAN), mirroring the PC Screen (uses LiveViewer software) infrastrcture mode (wireless LAN), Simple Access Point (SoftAP), SNMP Management (SNMP)

OSD Languages
English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkish, Arabic, Persian, Czech, Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian, Thai, Portuguese (Brazil), Indonesian, Vietnamese"

Compatibility
Computer Compatibility
IBM Compatible VGA, SVGA, XGA, WXGA WXGA+/SXGA/SXGA+/UXGA (compressed) MAC16"

Composite/S-Video
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43

Component Video
525i(480i), 525p(480p), 625i(575i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

HDMI Video
Video signals: 525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60),750p(720p@50/60), 1125p(1080p@50/60)"

Plug & Play
DDC2B (VESA)

Optical
Resolution
WXGA (1280 x 800)

Brightness
3700 ANSI Lumens (Normal) / 3034 ANSI Lumens (Eco1) / 2479 ANSI Lumens (Eco2)

LCD Panel
0.59" aspect ratio 16:10

Contrast Ratio
10,000:1

Lens
Manual Focus, Manual Zoom x 1.2

Lamp Wattage
225W

Lamp Life
5000 hours (Normal Mode) / 8000 hours (Eco Mode 1) / 10,000 hours (Eco Mode 2)

Diagonal Display Size
30~300" (76~762cm)

Number Of Colours
16.7 million colours

Keystone
Fixed 13:1 upward shift, Normal at + 10.3° ~ 8.6° projection angle

Focus Distance
0.9 ~ 9.6 m (WIDE), 1.1~11.6 m (TELE)

Distance To Width Ratio
1.5 (Wide), 1.8 (Tele)
