Optyka
Panel Size
16mm (0.63 inches), 4:3 Aspect Ratio

Rozdzielczość
XGA (1024 x 768)

Jasność
3200 ANSI Lumens (Normal)

Panel Structure
3LCD

Współczynnik kontrastu
10,000:1

Lamp Life (Hours)
10000 (Normal), 5000 (Whisper)

Obiektyw
Built-in

Lens Zoom
Manual Zoom x 1.2

Lens Focus
Manual Focus

Projection Lens F Number
F = 19 – 23

Throw Distance
0.9m-10.9m

Stosunek odległości do szerokości ekranu
1,5 (szerokokątny), 1,8 (teleobiektyw)

Display Size Diagonal
30 – 300 inches

Cechy i funkcje
Cyfrowa korekcja trapezu
(Horizontal: +30 degree Vertical: +30 degrees)

Picture Modes
Normal, Cinema, Dynamic, Board (Black), Board (Green), Whiteboard, Daytime, Photo, DICOM SIM

Korekty obrazu
ASPECT selection (Normal/4:3/16:9/16:10/14:9/Zoom), Perfect Fit (4 corners and 4 sides), Frame Lock (Data signal with vertical frequency of 49 to 51 Hz, 59 to 61 Hz), HDCR, Image blank by RS232C/Remote control, Image Optimizer, Magnify, Mirror Reverse Image, Up-side Down Image

Sieć
AMX Device Discovery, Command Control via the Network, Configuring and Controlling the Projector via a Web Browser, Controlling the Projector via Scheduling, Crestron RoomView® (Not accessible through the wireless adapter), Displaying text data transferred via network, Failure and Warning Alerts via E-mail, My Image (still image transfer) Display, Network Bridge, Network Presentation (PC still picture transfer), Frame rate (practical) is under 12fps (640x480 movie)

Security
PIN Security Lock, MyScreen Password Lock, Transition Detector, MyText Password Lock, Key Lock (Key pad, Remote Control)

Languages
34 Languages (English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkey, Arabian, Persian,Czech, Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian, Thai, Portuguese (Brazil), Indonesian, Vietnamese, Hebrew)

Złącza
Wejście cyfrowe
HDMI/MHL x1, HDMI x1 (Supporting HDCP decoding)

Analogue Input
15 pin Mini D-Sub x 2, RCA Jack x 1

Video Output
15-pin mini D-sub x 1

Wejście audio
3.5mm Stereo Mini Jack x 1, RCA Jack (L/R) x 1

Audio Output
3.5mm Stereo Mini Jack x 1

Sterowanie (RS-232C)
9-stykowe złącze D-sub x 1

Bezprzewodowa sieć LAN
Yes (Optional) / Yes (RJ45)

Wired LAN
Yes

USB Type A
Used for PC-less presentation or wireless network. Used for optional wireless pen tablet TB-1

USB typu B
Used for Remote control mouse or PC screen display

Moc
Zasilanie
AC 100V-120V / AC 220V-240V (50/60 Hz)

Power Consumption Operating
320W

Pobór mocy/tryb gotowości
<0,5 W

Parametry fizyczne
Masa
3,3 kg

Wymiary (szer. x wys. x głęb.)
325 x 95 x 245mm

Noise
37db (Normal), 32db (Whisper)

Filter Life (hours)
10000

Zgodność
Computer
IBM Compatible VGA, SVGA, XGA,WXGA/WXGA+/SXGA/SXGA+/UXGA (compressed) MAC16

HDMI
Video signals: 525i (480i), 525p (480p), 625i (576i), 1125i (1080i@50/60), 750p (720p@50/60), 1125p (1080p@50/60)

Akcesoria
Akcesoria w zestawie
Power cord EU model: Euro cord (1.8 m) x1 / US model: US cord (1.8m), Computer Cable (2 m) x1, IR Remote Control Unit x1, 'AA' Batteries x2, Lens cover x 1, Adapter Cover x1, Security Label x1, Application CD x1, User's Manual CD (Operating Guide, Network Function, Safety Instructions, User's Manual (Concise) x 1

Pilot zdalnego sterowania
HL03031

Lamp Model
DT02051

Replacement Lamp / Filter
UX39561(Hybrid Filter)

Projector/ Lamp Warranty
3 years / 3 years (for education and extended warranties please contact your local dealer)
