PANEL
Screen Size 86"
Panel Technology IPS
Aspect Ratio 16 : 9
Brightness 410 cd/m2 *
Viewing Angle(H x V) 178 x 178
Response Time 8 ms (G to G)
Surface Treatment Low Haze 3%
CONNECTIVITY
Input HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0
Output Touch USB 2.0 (2)
External Control RS232C, RJ45
PHYSICAL SPECIFICATION
Bezel Color Black
Bezel Width 50.7 mm (T/L/R), 62.2 mm (B)
Monitor Dimension (W x H x D) 79.8" x 46.5" x 3.8"
Weight (Head) 204.5 lbs
Carton Dimensions (W x H x D) 86.2" × 57.9" × 14.6"
Packed Weight 267.2 lbs
Handle Yes
VESA™ Standard Mount Interface 600 mm x 400 mm
SPECIAL FEATURES
Yes Temperature Sensor, Auto Brightness Sensor, ISM method, DPM Select, Brightness Control, PM Mode, Reader Mode, Crestron SDK, Wake on LAN, Energy Saving, File Play with USB, 2 PIP/PBP, Internal Memory (64GB), Wi-Fi (802.11n Combo built-in), USB Cloning, Failover, No Signal Image, Mirroring, Soft AP, BEACON
ENVIRONMENT CONDITIONS
Operation Temperature Range 32 °F to 104 °F
Operation Humidity Range 10% to 80%
POWER
Power Supply 100-240V~, 50/60Hz
Power Type Built-in Power
Power Consumption Typ. Under 330 W
Power Consumption-Smart Energy Saving on Under 200 W
STANDARD (CERTIFICATION)
Safety UL / cUL / CB / TUV / KC
EMC FCC Class "A" / CE / KCC
ErP / Energy Star NA
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible Yes
External Media player Attachable No
SOFTWARE COMPATIILITY
Content Management Software SuperSign Premium
Control and Monitoring Software SuperSign Link
EMBEDDED COLLABORATION AND WRITING SOFTWARE
Yes SuperSign IDB
ACCESSORY
Basic Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Eyebolt (2ea)
Optional OPS Kit (KT-OPSA), LSW640A/B (Wall Mount)
TOUCH SPECIFICATIONS
Touch type InGlass™**
Available object size for touch more than Ø 3 mm
Accuracy 2 mm + 0.2 mm
Interface USB 2.0
Protection Glass Thickness 4T (Anti-Glare)
Multi touch point Max 20 Point
