PANEL
Screen Size 27"Panel Technology IPS
Back Light Type EdgeAspect Ratio 16:9
Native Resolution 1920x1080 (FHD)Refresh Rate 60Hz
Brightness 300nitContrast Ratio 1,000:1
Color gamut NTSC 72%Viewing Angle(H x V) 178 X 178
Color Depth 8bit, 16.7 Million colorsResponse Time 9ms (G to G)
Surface Treatment(Haze) Anti glare, 3H(Haze 25%)Life time 31,000 Hrs (min)
Operation Hours (Hours/Day) 16/7Portrait / Landscape Yes / Yes
CONNECTIVITY(JACK INTERFACE)
Input HDMI (2, HDCP1.4), RS232C IN, RJ45(LAN), IR IN, USB2.0 Type AOutput Audio Out, Touch USB (USB2.0 Type B)
MECHANICAL SPECIFICATION
Bezel Color SilverBezel Width 7.7/7.7/7.7/9.7mm
Weight(Head) 4.2KgPacked Weight 6.2Kg
Monitor Dimension(W x H x D) 614.9 x 355.3 x 15.1mmCarton Dimensions(W x H x D) (Box outer size) 707 x 171 x 451mm
VESATM Standard Mount Interface 200x100
KEY FEATURE(HARDWARE)
Internal Memory 8GB(System 5GB + Available 2.48GB)Temperature Sensor Yes
Acceleration(Gyro) Sensor Yes
KEY FEATURE(SOFTWARE)
webOS ver. webOS 6.0Embedded CMS Local Contents Scheduling, Group Manager
USB Plug & Play YesFail over Yes
Background Image Booting Logo Image, No Signal ImageVideo Tag Yes
Play via URL YesGapless Playback Yes
Setting Data Cloning YesSNMP Yes
ISM Method YesStatus Mailing Yes
Control Manager Yes3rd Party Compatibility Crestron Inside
Power Smart Energy Saving, PM mode, Wake on LAN, Network ReadyHDMI-CEC Yes
SI Server Setting YeswebRTC Yes
Pro:Idiom Yes
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °COperation Humidity 10% to 80%
POWER
Power Supply AC 100-240V~, 50/60HzPower Type Built-In Power
POWER CONSUMPTION
DPM 0.5W↓Power off 0.5W↓
CERTIFICATION
Safety CB / NRTLEMC FCC Class "A"/ CE / KC
ErP Yes
SOFTWARE COMPATIBILITY
SuperSign CMS YesSuperSign Control / Control+ Yes
Signage 365 Care Yes
LANGUAGE
OSD English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic, Turkish, Polski
ACCESSORY
Basic Power Cord 1.55 M*1, USB Cable (Type A-Type B) 1.8 M*1, User Manual, QSG, Remote Controller(include battery 2ea), RS232C Gender, IR Receiver
SPECIAL FEATURE
Touch - Available object size for touch Ø6 mm ↑Touch - Reponse Time(PC Win10 Paintbrush) 90ms ↓
Touch - Accuracy 3.5mm±0.5mmTouch - Interface USB2.0
Touch - Operating System Support Win 10Touch - Multi touch point Max 10 Points
