PANEL
Screen Size 98"Panel Technology IPS
Back Light Type DirectAspect Ratio 16 : 9
Native Resolution 3,840 x 2,160 (UHD)Refresh Rate 60 Hz
Brightness 490nit (wo Glass Max.),390nit (wo Glass Typ.), 335nit (wo Glass, Min.)
450nit (w Glass, Max.),350nit (w Glass, Typ.), 300nit (w Glass Min.)Contrast Ratio 1,200:1
Color gamut NTSC 72%Viewing Angle (H x V) 178 x 178
Color Depth 10bit, 1.07Billion colorsResponse Time 8ms (G to G)
Surface Treatment(Haze) Anti Glare, 7Mohs, Haze 28%Life time 30,000 Hours (Min.)
Operation Hours (Hours/Day) 16 / 7Portrait / Landscape No / Yes
CONNECTIVITY(JACK INTERFACE)
Input HDMI (3, HDCP2.2/1.4),Audio In, RS232C IN, RJ45(LAN), IR IN, USB3.0 Type A(4), USB2.0 Type A(1), USB3.1 Type C (1, USB-PD, DP-Alt. Mode)Output HDMI Out, Audio Out, Optical,Touch USB (2), RJ45(LAN)
MECHANICAL SPECIFICATION
Bezel Color BlackBezel Width 29.6/26.6/26.6/44.5mm
Weight(Head) 103.55KgPacked Weight 126.50Kg
Monitor Dimension(W x H x D) 2244.7×1323.2×89.5mmCarton Dimensions(W x H x D) (Box outer size) 2406×280×1474mm
Handle YesVESA™ Standard Mount Interface 800 x 600
KEY FEATURE
HW Internal Memory 32GB, Built-in Wi-Fi (Slot type), Power Indicator, Local Key OperationSW webOS ver. (Android 9.0), Background Image (Booting Logo Image), Screen Share (Screenshare pro), 3rd Party Compatibility Crestron Inside, Power (Smart Energy Saving, PM mode, Wake on LAN, Network Ready), HDMI-CEC
ENVIRONMENT CONDITIONS
Operation Temperature 0 °C to 40 °COperation Humidity 10% ~90%RH
POWER
Power Supply 100-240V~ 50/60Hz 6.0Power Type Built-In Power
POWER CONSUMPTION
Typ. 460WMax. 630W
BTU (British Thermal Unit) 1570 BTU/Hr(Typ.), 2150 BTU/Hr(Max)DPM Yes
Power off 0.5W↓
SOUND
Speaker Yes (12W x 2)
CERTIFICATION
Safety CB / NRTLEMC FCC Class "A" / CE
ErP / Energy Star Yes / No
OPS COMPATIBILITY
OPS Type Compatible Yes (Slot)OPS Power Built In Yes
SOFTWARE COMPATIBILITY
Signage 365 Care Yes
LANGUAGE
OSD English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands（Dutch), Norwegian, Polski, Portugues(Europe),Portugues(Brazil) Romanian, Russian, Spanish, Swedish, Turkish, Ukrainian, Traditional Chinese, Hungarian, Latvian, Thai
ACCESSORY
Basic Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
SPECIAL FEATURE
Touch - Available object size for touch Ø3 mm ↑Touch - Reponse Time ≤12ms
Touch - Writing Height ≤3mmTouch - Accuracy ±1.5mm
Touch - Interface USB 3.0Touch - Protection Glass Thickness 4T (Anti-Glare)
Touch - Protection Glass Transmission 87%Touch - Operating System Support Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
Touch - Multi touch point Max 20 Points
ANDROID SYSTEM
SoC Quad Core A73GPU Mail G52 Multi Core 2
Internal Memory - Storage 32GBInternal Memory - RAM 4GB
Wi-Fi 802.11a/b/g/n/acLAN Gigabit LAN
Bluetooth Bluetooth 5.0
