Panel
Screen Size 46.96" (1192.78mm) diagonal
Panel Technology IPS
Aspect Ratio 16 : 9
Native Resolution 1920 x 1080 (FHD)
Brightness 300cd/m2
Contrast Ratio 1,200:1
Dynamic CR 500,000:1
Color gamut 68%
Viewing Angle (H x V) 178 x 178
Color Depth 16.7 Million
Response Time 8 ms
Surface Treatment Hard coating (3H), Anti-glare treatment of the front polarizer (Haze 1%(Typ.))
Life time 50,000 Hrs
Orientation Portrait & Landscape
Connectivity
Input ------------------------------------
Digital HDMI (1)
Analog RGB (1)
Audio Yes (1)
External Control RS232C(1), RJ45(1), IR(1)
USB Yes (1)
HDTV Formats HDMI : 720p, 1080i, 1080p
Output ------------------------------------
Audio Yes (L/R)
External Control RS232C (1)
Video
Max Input Resolution 1920 X 1080@ 60Hz (RGB,HDMI)
Recommended Resolution 1920 X 1080@ 60Hz (RGB,HDMI)
H-Scanning Frequency 30 ~ 68 kHz (RGB, HDMI)
V-Scanning Frequency 56Hz ~ 75Hz (RGB), 50Hz~63Hz (HDMI)
Pixel Frequency 148.5 MHz (RGB, HDMI)
Sync Compatability Separate / Digital
Video Input RGB, HDMI
Picture mode Vivid, Standard, APS, Cinema, Sport, Game, Expert1, Expert2
Color temperature Warm, Medium, Cool
Audio
Balance Yes
Audio Power 20W (10W x 2) for External Speaker
Speaker On/off Yes
Clear Voice II Yes
Sound mode Standard, New, Music, Cinema, Sport, Game
Physical Specification
Color Black
Monitor Dimension (W x H x D) 107.1cm x 62.16cm x 5.58cm
Weight (head) 12.2kg
Monitor with Optional Stand 107.1cm x 67.51cm x 24.7cm
Weight(Head+Stand) 12.5kg
Monitor with Optional Stand & Speaker Dimensions(W x H x D) 107.1cm x 67.51cm x 24.7cm
Weight(Head+Stand+Speaker) 13.3kg
VESA Standard Mount Interface 400mm x 400mm
Special Features
Temperature Sensor Yes
Tile Mode Yes, Up to 15 x 15
Source Selection RGB, HDMI, USB
Brightness/Contrast/Backlight Yes
Position/Size Yes
Auto Config/Phase Yes
Language (OSD) English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek
Language (USB Playback) English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek
Language (Manual) English, French, Italian, German, Spanish, Portugues, Hungarian, Greek, Russian, Dutch, Kazakh, Ukrainian, Polish, Arabic, Indonesian, Korean, Japanese, Turkish, Czech, Taiwanese, Slovak
Language (ESG) English, French, Italian, German, Spanish, Portugues, Greek, Polish, Czech, Slovak
ISM Method Normal, White Wash
Advanced Dynamic Contrast, Dynamic Color, Skin Color, Sky Color, Grass color, Gamma
Time Clock, On/Off Time, Auto Off, Automatic Standby
Information Model/Type, Software Version, Serial Number, IP Address, MAC Address, Homepage
Input Label Yes(PC/DTV)
Auto Power/Source Memory Yes
Key Lock Yes
DPM Select Yes
Energy Saving Yes (Minimum, Medium, Maxium, Screen off)
Smart Energy Saving Yes
File Play with USB Yes
Wi-Fi Dongle ready
Environment Conditions
Operation Temperature 0°C ~ 40°C
Operation Humidity 10% ~80%
Power
Power Supply 100-240V~, 50/60Hz
Power Type (Adapter or LIPS) Built-in Power
Power Consumption (Typ.) 73W
Power Consumption (Smart Energy Saving) 50W (Typ)
Power Consumption (DPM) 0.5W(RGB), 0.7W(HDMI)
Power Consumption (Power off) 0.5W
Standard (Certification)
Safety UL / c-UL / CB / TUV / KC
EMC FCC Class "A", CE, KCC
ErP / Energy Star Yes / Yes (Energy Star 6.0)
Media Player Compatibility
External Media player Attatchable Yes (MP500/MP700)
Software Compatibility
SuperSign-w lite Yes
SuperSign-c Yes
