47" class (46.96" diagonal) Full HD Display
47LS55A-5B
PANEL
Panel Size
Brightness
Panel Type
Viewing Angle (H x V)
Response Time
Contrast Ratio (Typ.)
Dynamic CR (DCR)
Native Resolution
47" class (46.96"" measured diagonally)
450 cd/m^2
IPS
178°/178°
11ms (G to G BW), 8ms (WOT)
1,200:1
500,000:1
1920 x 1080 (FHD)
OPTIONAL ACCESSORIES
Stand
Speaker
Pixel Sensor
ST-471T
SP-2100
KT-SP0
SIGNAL (OUTPUT)
Digital
Analog
External Control
Display Port (1)
External Speaker (1)
RS232C (1)
CABINET
Bezel Width
Color
Flat Bezel : 8.5mm(L/R/U), 14.0mm(B) After Curvature : 13.2mm(L/R/U), 18.7mm(B)
Black
DIMENSIONS
Monitor (W x H x D)
Weight (lbs)
Monitor w/opt stand
Weight w/ Monitor & opt stand (lbs)
Monitor w/opt std/spk
Weight w/ opt std & spk(lbs)
Weight with Carton (lbs)
Carton
VESA Standard Mount Interface
42.1'x 24.4"x 2.1"
26.8
42.1"x 26.5"x 9.7'
27.5
42.1"x 26.5"x 9.7'
29.3
35.0
45.2"x 27.9"x 5.9"
400mm x 400mm
SPECIAL FEATURES
IPS Panel
High-Performace & Cost-Effective Solution
Internal Memory
webOS for signage platform
Low Screen Temperature on Standard Mode, High Resistance to Blackening Defect, Wide Viewing Angle
Embeded Media Player, Enhanced Failover to Internal Memory, Supports SNMP (Simple Network Management Protocol), Pixel Sensor for Screen Failure Detection
8GB (System 4GB + Available 4GB)
Web Centric Platform, Simple Customization, Intuitive UX, Simple management
ENVIRONMENT CONDITIONS
Operation Temperature
Operation Humidity
0°C-40°C (32°F-104°F)
10%~80%
POWER
Normal On (Typ.)
Smart Energy Saving Off/On
95W
70W
STANDARD CERTIFICATIONS
Safety
EMC
ErP/Energy Star
UL / cUL / CB / TUV / KC
FCC Class "A" / CE / KCC
Yes / Yes (Energy Star 6.0)
WARRANTY
Warranty
3-Year Limited Warranty (Parts/Labor/Backlight)
UPC Code
47LS55A-5D
7 19192 19543 1
MEDIA PLAYER COMPATIBILITY
External Media Player Attatchable
Yes (MP500/MP700)
SIGNAL (INPUT)
Digital
USB
HDMI (2), Display Port (1), DVI (1)
Yes (1)
ACCESSORIES
Accessories
Remote Controller(include battery 2ea), Power Cord, IR/Light sensor receiver, CD(Owner's Manual, SuperSign Program / Manual), HDMI Cable
SOFTWARE COMPATIBILITY
SuperSign Elite-c
SuperSign Elite-w lite
Yes (SuperSign software is available from website.)
Yes, Editing, Scheduling, Distribution & Play, Control
