General
Screen size (inches) 55
Aspect Ratio 16:9
Resolution 1920 x 1080
Brightness (cd/m2) 500
Contrast Ratio 1,300:1, 500,000:1 (DCR)
Response Time (ms) 8
Viewing Angle (°) 178 x 178
Surface Treatment Hard coating(3H), Anti-glare treatment of the front polarizer (Haze 10%)
Colour Depth (Num of Colours) 1.07 Billion
Video
Max Input Resolution 1920 x 1080@60Hz(HDMI, DVI-D, Display Port, OPS)
Recommended Resolution 1920 x 1080@60Hz(HDMI, DVI-D, Display Port, OPS)
H-Scanning Frequency 30 ~ 83kHz(HDMI, DVI-D, Display Port, OPS)
V-Scanning Frequency 60Hz(HDMI, DVI-D, Display Port, OPS)
Pixel Frequency 148.5MHz(HDMI, DVI-D, Display Port)
Sync Compatability Digital
Video Input HDMI1, HDMI2/OPS, DVI-D, Display Port
Picture Mode Vivid, Standard , APS, Cinema, Sport, Game, Expert1, Expert2
Colour temperature Warm / Medium / Cool
Connectivity - Input
Digital HDMI(2), OPS, DP(1), DVI-D(1)
Audio YES(1)
External Control RS232C, RJ45, IR/Light sensor, Pixel Sensor
USB Yes(1)
HDTV Formats HDMI : 720p, 1080i, 1080p
Connectivity - Output
Digital Display Port(1)
Audio External Speaker
External Control RS232C(1)
Audio
Audio Power 20W (10W x 2)
Balance Yes
Speaker On/off Yes
Clear Voice II Yes
Sound mode Standard, News, Music, Cinema, Sport, Game
Special Features
Temperature Sensor Yes
Auto Brightness sensor Yes
Tile Mode Yes, Up to 15 x 15
Natural Mode @Tile Mode Yes
Source Selection DVI-D, HDMI, Display Port, USB, OPS
Brightness/Contrast/Backlight Yes
Advanced Dynamic Contrast, Dynamic Color, Clear White, Skin Color, Noise Reduction, Digital Noise Reduction, Gamma, Black Level
Time Clock, On/Off Time, Sleep Timer, Power on Delay, Auto Off, Automatic Standby
Input Label Yes(PC/DTV)
Auto Power/Source Memory Yes
Key Lock Yes
DPM Select Yes
Internal Memory 16GB(System 4GB + Available 12GB)
Smart Energy Saving Yes
Wi-Fi Dongle ready
Standard (Certification) & VESA Mounting
Safety UL / cUL / CB / TUV / KC
EMC FCC Class "A" / CE / KCC
ErP / Energy Star NA / Yes (Energy Star 6.0)
VESA Mounting 400 x 400
Power
Power Supply 100-240V, 50/60Hz
Power Type Built-in Power
Power Consumption Typ.:140W, Smart Energy Saving:100W, DPM:0.7W, Power off:0.5W
Dimensions - WxHxD (mm)
Monitor 123.0cm x 71.4cm x 3.2cm
Monitor with Optional Stand 123.0cm x 77.6cm x 29.8cm
Monitor with Optional Stand & Speaker Dimensions 123.0cm x 77.6cm x 29.8cm
Weight (kg)
Monitor 20.7
(Head+Stand) 22.1
(Head & Stand & Speaker) 22.9
MEDIA PLAYER COMPATIBILITY
OPS type compatible Yes
External Media player Attachable Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
Supersign Compatibility SuperSign-w lite, SuperSign-c
ECO
